Lexus RX II (2003-2006) head auto off tail head wiring diagram
This page shows the only wiring diagram for the component.head auto off tail head, which is found in the car Lexus RX II (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
head auto off tail head wiring diagram (1 of 1)
1 7 5 10 BUS LINE BUS GND IG PGND
AUTO
AUTO OFF TAIL HEAD
BLK WIRE
BLU WIRE
BODY ECU (BEHIND LEFT SIDE OF DASH)
BRN WIRE
COMBINATION SWITCH
COMPUTER DATA LINES SYSTEM
EC (AT REAR OF SURGE TANK)
GRY WIRE
HEAD AUTO OFF TAIL HEAD
HEAD TAIL
HEADLIGHTS CIRCUIT
IC 1
IC 2
IC 3
II (AT LEFT KICK PANEL)
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
J/B 3 (LEFT SIDE OF DASH)
J/C 3
LEFT HEADLIGHT
LEFT HEADLIGHT BEAM LEVEL CONTROL MOTOR
LEFT HEADLIGHT SWIVEL ECU
LEFT HEADLIGHT SWIVEL MOTOR
LT GRN WIRE
MAGNET
MOTOR
MOTOR U
MOTOR V
MOTOR W
OFF TAIL
ORG/ WIRE
PNK 1 3 2 4 WIRE
PNK 9 10 WIRE
RED WIRE
RIGHT HEADLIGHT
RIGHT HEADLIGHT BEAM LEVEL CONTROL MOTOR
RIGHT HEADLIGHT SWIVEL ECU
RIGHT HEADLIGHT SWIVEL MOTOR
U-OUT
V OUT
VIO WIRE
W-OUT
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Adaptive front lighting circuit (2 of 2) -> HEAD AUTO OFF TAIL HEAD
