Car Wiring Diagrams for Heated seats circuit for Lexus RX I (1997-2003)

BLK WIRE BLU WIRE DRIVER'S SEAT HEATER HI DRIVER'S SEAT HEATER SWITCH GAUGE FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) J/B 3 (BEHIND UPPER CENTER OF DASH) J/B 5 (BEHIND UPPER LEFT SIDE OF DASH) J/C 15 (UNDER RIGHT REAR SEAT) J/C 17 (UNDER DRIVER'S SEAT) J/C 18 (UNDER PASSENGER'S SEAT) LO HI LT GRN WIRE PASSENGER'S SEAT HEATER LO PASSENGER'S SEAT HEATER SWITCH RED WIRE SEAT HEATER RELAY (BEHIND RIGHT SIDE OF DASH, NEAR ECM) SEAT HTR FUSE WHT WIRE
