Lexus RX I (1997-2003) traction cut switch hazard switch Wiring diagram
This page shows the only wiring diagram for the component.traction cut switch hazard switch, which is found in the car Lexus RX I (1997-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram traction cut switch hazard switch (1 of 1)
BLK WIRE
BODY ECU
BRN WIRE
CD AUTOMATIC CHANGER RADIO, PLAYER
CIGARETTE LIGHTER
COMBINATION METER ECU
DAYTIME RUNNING LIGHT RESISTOR (OR SHORT CONNECTOR)
DRIVER'S SEAT HEATER SWITCH
DRL 3 RELAY
DRL 4 RELAY
ELECTRONIC CONTROLLED TRANSMISSION PATTERN SELECT SWITCH
ENGINE HOOD COURTESY SWITCH
FROM J/B 3 (DIAGRAM 2 OF 5)
FROM J/C 1 (DIAGRAM 1 OF 5)
FRONT PASSENGER'S SEAT HEATER SWITCH
FUEL SENDER (SUB)
GLOVE BOX LIGHT
GND 1 8 6
GND 2
GND 9 7
GND GND 2 20
INSTRUMENT CONTROL PANEL
J/B 3 (BEHIND UPPER CENTER OF DASH)
J/C 1 (IN ENGINE COMPARTMENT, ON RIGHT FRONT FENDER)
MULTI-DISPLAY
O/D MAIN SWITCH
R/B 3 (ON FRONT CENTER OF ENGINE COMPARTMENT, ON RADIATOR SUPPORT)
REMOTE CONTROL MIRROR SWITCH
RIGHT FRONT SIDE MARKER LIGHT
RIGHT PARKING LIGHT
SEAT MEMORY SWITCH
SHIFT LOCK ECU
THEFT DETERRENT INDICATOR LIGHT
TO J/B 3 (DIAGRAM 2 OF 5)
TO J/B 5
TRACTION CUT SWITCH HAZARD SWITCH
W/O NAVIGATION W/ NAVIGATION
WASHER LEVEL WARNING SWITCH
WHT WIRE
Go to component -> Ground distribution circuit (2 of 5) -> TRACTION CUT SWITCH HAZARD SWITCH
