Lexus RX I (1997-2003) right turn indicator Wiring diagram
This page shows the only wiring diagram for the component.right turn indicator, which is found in the car Lexus RX I (1997-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right turn indicator (1 of 1)
2 INDICATOR
5 12 PI SPD
A/T OIL TEMP INDICATOR
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU/WHT WIRE
BRAKE INDICATOR
BRN WIRE
BRN/WHT WIRE
COMBINATION METER ECU
CRUISE CONTROL ECU (BEHIND LEFT SIDE OF DASH)
CRUISE CONTROL, ENGINE CONTROL, NAVIGATION SYSTEMS
DATA LINK CONNECTOR (DLC) 3 (PARTIAL) (UNDER LEFT SIDE OF DASH)
DRIVER DOOR ECU (IN LEFT FRONT DOOR)
ECT SNOW INDICATOR
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
ENGINE CONTROLS SYSTEM
FUEL GAUGE
FUEL INDICATOR
FUEL SENDER (MAIN) (ON TOP OF FUEL TANK)
FUEL SENDER (SUB) (UNDER CENTER OF VEHICLE)
GRN WIRE
GRN/BLK WIRE
GRN/YEL WIRE
GRY/BLU WIRE
HEADLIGHTS SYSTEM
HEADLIGHTS SYSTEM ANTI-LOCK BRAKES SYSTEM
HEATER FUSE
HOT AT ALL TIMES
HOT IN ON OR START
INDICATOR
INSTRUMENT CONTROL PANEL
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
J/B 3 (BEHIND UPPER CENTER OF DASH)
LEFT TURN INDICATOR
LIGHT FAILURE SENSOR (IN LEFT SIDE OF LUGGAGE COMPARTMENT)
LT GRN/BLK WIRE
LT GRN/RED WIRE
MPX
ODLP
ODNS
OIL INDICATOR
ORG/ WIRE
PNK WIRE
REAR LIGHTS INDICATOR
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT TURN INDICATOR
SEAT BELT INDICATOR
SOLID STATE
SPEEDOMETER
SRS-B FUSE
SUPPLEMENTAL RESTRAINTS SYSTEM
TACHOMETER
TO COMBINATION METER ECU (DIAGRAM 2 OF 2)
VIO/WHT WIRE
WATER TEMP GAUGE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED (OR YEL/BLK) WIRE
YEL/RED WIRE
Go to component -> Instrument cluster circuit (1 of 2) -> RIGHT TURN INDICATOR
