Lexus RX I (1997-2003) body computer system, warning systems Wiring diagram
This page shows the only wiring diagram for the component.body computer system, warning systems, which is found in the car Lexus RX I (1997-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram body computer system, warning systems (1 of 1)
AIR CONDITIONING SYSTEM, NAVIGATION SYSTEM, POWER ANTENNA SYSTEM, SOUND SYSTEMS
BLK WIRE
BODY COMPUTER SYSTEM, WARNING SYSTEMS
CELLULAR TELEPHONE SYSTEM, NAVIGATION SYSTEM, POWER ANTENNA SYSTEM, SOUND SYSTEM
CIG FUSE
CIGARETTE LIGHTER
FROM IGNITION SWITCH (CAVITY 3) (DIAGRAM 3 OF 4)
FROM TAILLIGHT RELAY (DIAGRAM 1 OF 4)
FRONT POWER OUTLET (REAR OF CENTER CONSOLE)
GRY WIRE
INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH)
J/B 3 (BEHIND UPPER CENTER OF DASH)
J/C 12 (IN LEFT SIDE OF LUGGAGE COMPARTMENT)
J/C 9 (RIGHT END OF DASH)
JUNCTION CONNECTOR (LEFT KICK PANEL)
MIRRORS SYSTEM
PNK WIRE
PWR OUTLET FUSE
RADIO 2 FUSE
REAR POWER OUTLET (LEFT REAR SIDE OF CARGO AREA)
RED WIRE
RELAY
SHIFT INTERLOCK SYSTEM
WHT WIRE
Go to component -> Power distribution circuit (4 of 4) -> BODY COMPUTER SYSTEM, WARNING SYSTEMS
