Lexus RX I (1997-2003) automatic cd changer Wiring diagrams
This page contains all the electrical diagrams for the component. automatic cd changer, in which he is found in the car Lexus RX I (1997-2003). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram automatic cd changer (1 of 2)
+B RL- GND FR- FR+ FL- FL+
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 -B
1 2 3 4 5 6 7 8 9 10 11 12 R+ L+ SGRD MUTE +B R- L- GND TX- TX+
1 2 3 4 5 6 7 8 9 10 RL+
1 2 3 4 5 6 WFR+ RR+ WFR- WF+ WF- RR-
10 3 6 11 4 TX- TX+ EJECT
3 10 4 11 TX+ TX-
ANT
AUTOMATIC CD CHANGER
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/YEL WIRE
BRN WIRE
DOME FUSE
ENGINE ROOM J/B (ON LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) RAD 2 FUSE
INSTRUMENT CONTROL PANEL
INSTRUMENT PANEL J/B
J/B 3 (BEHIND UPPER CENTER OF DASH)
J/B 5 (BEHIND UPPER LEFT SIDE OF DASH)
J/C 15 (UNDER RIGHT REAR SEAT)
J/C 4 (BEHIND LEFT KICK PANEL)
L-R
LEFT FRONT DOOR SPEAKER
LEFT REAR DOOR SPEAKER
LEFT TWEETER
LT GRN WIRE
MULTI-DISPLAY
MUTE R+ L+ SGND
NAVAIGATION ECU (ON RIGHT REAR OF CARGO AREA)
NCA WIRE
PNK TX- WIRE
PNK WIRE
PNK/BLK WIRE
PNK/BLU WIRE
POWER ANTENNA SYSTEM
R- L- GND
RAD 1 FUSE
RADIO, PLAYER
RED WIRE
RED/WHT WIRE
RIGHT FRONT DOOR SPEAKER
RIGHT REAR DOOR SPEAKER
RIGHT TWEETER
STEREO COMPONENT AMPLIFIER (UNDER REAR SEAT)
TELEPHONE ECU (ON RIGHT REAR OF CARGO AREA)
TX- TX+ EJECT
VIO WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WOOFER SPEAKER
YEL WIRE
Go to component -> Radio circuits, with navigation -> AUTOMATIC CD CHANGER
Wiring diagram automatic cd changer (2 of 2)
+B RL- GND FR- FR+ FL- FL+
1 2 3 4 5 6 7 8 9 10 11 12 R+ L+ SGRD MUTE +B R- L- GND TX- TX+
1 2 3 4 5 6 7 8 9 10 R+ L+
1 2 3 4 5 6 7 8 9 10 RL+
1 2 3 4 5 6 7 TX- TX+
1 2 3 4 5 6 WFR+ RR+ WFR- WF+ WF- RR-
11 7 5 10 6 TX- TX+ EJECT
ANT EJECT
AUTOMATIC CD CHANGER
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/YEL WIRE
BRN WIRE
DOME FUSE
ENGINE ROOM J/B (ON LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON INSTRUMENT PANEL J/B (BEHIND LEFT SIDE OF DASH) RAD 2 FUSE
INSTRUMENT CONTROL PANEL
INSTRUMENT PANEL J/B
J/B 3 (BEHIND UPPER CENTER OF DASH)
J/B 5 (BEHIND UPPER LEFT SIDE OF DASH)
J/C 15 (UNDER RIGHT REAR SEAT)
J/C 4 (BEHIND LEFT KICK PANEL)
L-R
LEFT FRONT DOOR SPEAKER
LEFT REAR DOOR SPEAKER
LEFT TWEETER
LT GRN WIRE
MULTI-DISPLAY
NCA WIRE
PNK WIRE
PNK/BLK WIRE
PNK/BLU WIRE
POWER ANTENNA SYSTEM
R- L- SGND MUTE TX- TX+
RAD 1 FUSE
RADIO, PLAYER
RED WIRE
RED/WHT WIRE
RIGHT FRONT DOOR SPEAKER
RIGHT REAR DOOR SPEAKER
RIGHT TWEETER
STEREO COMPONENT AMPLIFIER (UNDER REAR SEAT)
TELEPHONE ECU (ON RIGHT REAR OF CARGO AREA)
TX- TX+
VIO WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WOOFER SPEAKER
YEL WIRE
Go to component -> Radio circuits, without navigation -> AUTOMATIC CD CHANGER
