Car Wiring Diagrams for Back door opener circuit, w/o power back door for Lexus NX Z10 facelift (2017-2021)

BACK DOOR LOCK ASSEMBLY BACK DOOR OPENER SWITCH ASSEMBLY BLK WIRE BLU WIRE CERTIFICATION ECU COMPUTER DATA LINES SYSTEM COURTESY CSEL D/L 2 FUSE D/L BACK RELAY DATA DIODE (COURTESY LIGHT) ECU-B 3 FUSE FUSE BLOCK ASSEMBLY HOT AT ALL TIMES INSTRUMENT PANEL J/B ASSEMBLY LOCK LT GRN WIRE MAIN BODY ECU RCO RDAM RED WIRE W/ POWER SEAT WHT WIRE WHT/BLK WIRE YEL WIRE
