# Rear sonar circuit, late production

# Rear sonar circuit, late production (1 of 2)

Navigation — Rear sonar circuit, late production — Rear sonar circuit, late production (1 of 2). Lexus NX Z10 facelift (2017-2021)
Components on the diagram

    # Rear sonar circuit, late production (2 of 2)

    Navigation — Rear sonar circuit, late production — Rear sonar circuit, late production (2 of 2). Lexus NX Z10 facelift (2017-2021)
    Components on the diagram
