Rear sonar circuit, early production for Lexus NX Z10 facelift (2017-2021)
Rear sonar circuit, early production (1 of 2)
BLK WIRE
BLU WIRE
CBZ
CLEARANCE SONAR
CLEARANCE WARNING ECU ASSEMBLY
COMBINATION SWITCH ASSEMBLY
COMPUTER DATA LINES SYSTEM
ECU-IG 2 FUSE
GRN WIRE
INSTRUMENT PANEL J/B ASSEMBLY
LEFT FRONT CENTER ULTRASONIC SENSOR 1
LEFT REAR ULTRASONIC SENSOR 1
LT GRN WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
RELAY ENERGIZED
RIGHT FRONT CENTER ULTRASONIC SENSOR 1
RIGHT REAR CENTER ULTRASONIC SENSOR 1
RIGHT REAR ULTRASONIC SENSOR 1
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Rear sonar circuit, early production (2 of 2)
BLK WIRE
BLU WIRE
CAN I/F
CLEARANCE WARNING BUZZER 1
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISPLAY DRIVER
GRN WIRE
HYBRID VEHICLE CONTROL ECU
INSTRUMENT PANEL J/B ASSEMBLY
LED DRIVER
LEFT FRONT ULTRASONIC SENSOR 1
LEFT REAR CENTER ULTRASONIC SENSOR 1
LT GRN WIRE
METER 2 FUSE
PNK WIRE
PSFT
RELAY ENERGIZED
RIGHT FRONT ULTRASONIC SENSOR 1
SHIFT LEVER POSITION SENSOR
TELLTALES
VIO WIRE
WHT WIRE
WHT/BLK WIRE
