Lane departure warning circuit, early production for Lexus NX Z10 facelift (2017-2021)

BLK WIRE BLU WIRE CAN I/F COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM DISPLAY DRIVER DRIVING SUPPORT ECU ASSEMBLY ECU- IG 1 FUSE ECU-IG 2 FUSE GRN WIRE GRY WIRE HEADLIGHT DIMMER SWITCH ASSEMBLY IGB INSTRUMENT PANEL J/B ASSEMBLY LANE DEPARTURE WARNING LANE DEPARTURE WARNING CAMERA LEFT TURN LEFT LANE CHANGE NEUTRAL RIGHT LANE CHANGE RIGHT TURN 1) 2) 3) 4) 5) LKSW LT BLU WIRE METER 2 FUSE MILLIMETER WAVE RADAR SENSOR ASSEMBLY PNK SPSW WIRE PNK WIRE RED WIRE RELAY ENERGIZED RIGHT END OF DASH) RIGHT STEERING PAD SWITCH STEERING PAD SWITCH ASSEMBLY SKID CONTROL BUZZER ASSEMBLY SPIRAL CABLE W/ SENSOR SUB-ASSEMBLY TURN SWITCH VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
