Lexus NX Z10 facelift (2017-2021) Cooling fan circuit

A/C AMPLIFIER ASSEMBLY A/C PRESSURE SENSOR BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COOLING FAN ECU COOLING FAN MOTOR COOLING FAN MOTOR 2 CRANK POSITION SENSOR E.F.I. ENGINE COOLANT TEMPERATURE SENSOR ECU- IG 1 FUSE ECU-IG 4 FUSE ENGINE ROOM R/B 2 FAN 1 RELAY FAN FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES INSTRUMENT PANEL J/B ASSEMBLY LT BLU WIRE NE+ ORG/ WIRE PNK WIRE RED WIRE RELAY ENERGIZED RFC SG-2 VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
