Lexus NX Z10 facelift (2017-2021) w/o seat position memory w/ seat position memory Wiring diagram
This page shows the only wiring diagram for the component.w/o seat position memory w/ seat position memory, which is found in the car Lexus NX Z10 facelift (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o seat position memory w/ seat position memory (1 of 1)
BLK WIRE
BLU WIRE
BRAKE BOOSTER W/ MASTER CYLINDER ASSEMBLY
CAN JUNCTION TERMINAL 3
FRONT TELEVISION CAMERA ASSEMBLY
GRN WIRE
GRY WIRE
LEFT BLIND SPOT MONITOR SENSOR
LEFT OUTER REAR VIEW MIRROR ASSEMBLY
LEFT SIDE TELEVISION CAMERA ASSEMBLY
LT BLU WIRE
PARKING ASSIST ECU
PNK WIRE
REAR TELEVISION CAMERA ASSEMBLY
RED WIRE
RIGHT BLIND SPOT MONITOR SENSOR
RIGHT OUTER REAR VIEW MIRROR ASSEMBLY
RIGHT SIDE TELEVISION CAMERA ASSEMBLY
VIO WIRE
W/O SEAT POSITION MEMORY W/ SEAT POSITION MEMORY
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Computer data lines circuit, late production (3 of 5) -> W/O SEAT POSITION MEMORY W/ SEAT POSITION MEMORY
