Lexus NX Z10 facelift (2017-2021) w/o safety connect w/ safety connect early production late production Wiring diagram

ABS MTR FUSE ABS- MAIN FUSE ACCD ALT FUSE AMP FUSE ANTI-LOCK BRAKES SYSTEM ANTI-LOCK BRAKES, ELECTRONIC POWER STEERING SYSTEMS ANTI-THEFT SYSTEM ASEL BATTERY BBC 2 FUSE BLK WIRE BLK/BLU WIRE BLK/DK GRN WIRE BLU WIRE BRN WIRE CERTIFICATION ECU (LOWER RIGHT SIDE OF DASH) D/C CUT FUSE D/L 1 FUSE DCM FUSE DIS DOME FUSE DOOR LOCKS SYSTEM DOOR LOCKS, ANTI-THEFT, TRUNK, TAILGATE, FUEL DOORS SYSTEMS ECU-B 1 FUSE ECU-B 2 FUSE ECU-B 4 FUSE ECU-B 5 FUSE EDU FUSE EFI- MAIN 1 FUSE EFI- MAIN 2 FUSE EFI- MAIN 3 FUSE ELECTRONIC POWER STEERING SYSTEM ELECTRONIC POWER STEERING, MEMORY SYSTEMS ENGINE CONTROLS SYSTEM ENGINE ROOM J/B 1 ENGINE ROOM R/B 1 ENGINE ROOM R/B 2 ENGINE SWITCH EPB 1 FUSE EPB 2 FUSE EPS FUSE ETCS FUSE GRN WIRE GRY WIRE H-LP MAIN LH/H-LP MAIN HI FUSE H-LP MAIN RH/H-LP MAIN LO FUSE HEADLIGHTS SYSTEM HORN FUSE HORNS SYSTEM IMMOBI FUSE INSTRUMENT CLUSTER SYSTEM LT GRN WIRE MAIN FUSIBLE LINK MEMORY SYSTEMS METER 1 FUSE MIRRORS SYSTEM MOBILE WIRELESS CHARGER CRADLE ASSEMBLY NAVIGATION SYSTEM NAVIGATION, SOUND SYSTEMS ODS FUSE ORG/ WIRE PNK WIRE R/B RH-B FUSE RADIO FUSE RED WIRE RIGHT END OF DASH) SEATS SYSTEM SHIFT INTERLOCK SYSTEM ST 1 FUSE STARTING/ CHARGING SYSTEM STRG LOCK FUSE SUPPLEMENTAL RESTRAINTS SYSTEM TAIL TO ENGINE ROOM J/B 2 (DIAGRAM 2 OF 4) TO ENGINE ROOM R/B 1 (DIAGRAM 2 OF 4) TO INSTRUMENT PANEL J/B ASSEMBLY (DIAGRAM 3 OF 4) TO INSTRUMENT PANEL J/B ASSEMBLY (DIAGRAM 4 OF 4) TRUNK, TAILGATE, FUEL DOORS SYSTEM TURN, HAZ FUSE VIO WIRE W/O SAFETY CONNECT W/ SAFETY CONNECT EARLY PRODUCTION LATE PRODUCTION WHT WIRE WHT/BLK WIRE YEL WIRE
