Lexus NX Z10 facelift (2017-2021) wht Wiring diagrams

This page contains all the electrical diagrams for the component. wht, in which he is found in the car Lexus NX Z10 facelift (2017-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

wht wiring diagram (111 of 231)

BLK WIRE BLU WIRE BRN WIRE CANN CANP COMBINATION METER ASSEMBLY DATA LINK CONNECTOR 3 DCM (TELEMATICS TRANSCEIVER) DIA GRN WIRE GRY WIRE HEADUP DISPLAY (COMBINATION METER MIRROR ECU) HOT AT ALL TIMES INSTRUMENT PANEL J/B ASSEMBLY LT GRN WIRE MSCH MSCL MULTI- DISPLAY ASSEMBLY OBD FUSE OCCUPANT DETECTION ECU PNK TAC WIRE PNK WIRE PRST RADIO RECEIVER ASSEMBLY RED WIRE REMOTE OPERATION CONTROLLER ASSEMBLY RIGHT END OF DASH) STEREO COMPONENT AMPLIFIER ASSEMBLY TX+ MO+ TX- PNK TX+ WIRE VEHICLE APPROACHING SPEAKER CONTROLLER VIO WIRE W/ LEXUS ENFORM, SAFETY CONNECT W/ NAVIGATION W/O NAVIGATION 8 SPEAKER 10 SPEAKER WFSE WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Computer data lines circuit, early production (1 of 3) -> WHT WIRE

wht wiring diagram (112 of 231)

BLK WIRE BLU WIRE BRN WIRE CANN CANP CLEARANCE WARNING ECU ASSEMBLY DRIVING SUPPORT ECU ASSEMBLY GRN WIRE GRY WIRE LANE DEPARTURE WARNING CAMERA LEFT BLIND SPOT MONITOR SENSOR MAIN BODY ECU MILLIMETER WAVE RADAR SENSOR ASSEMBLY MULTIPLEX NETWORK DOOR ECU PNK WIRE REAR TELEVISION CAMERA ASSEMBLY RED WIRE RIGHT BLIND SPOT MONITOR SENSOR RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY VIO WIRE W/ MEMORY WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Computer data lines circuit, early production (3 of 3) -> WHT WIRE

wht wiring diagram (113 of 231)

ACL BLK WIRE BLU WIRE CANN CANP DATA LINK CONNECTOR 3 DCM (TELEMATICS TRANSCEIVER) DIA GRY WIRE HOT AT ALL TIMES INSTRUMENT PANEL J/B ASSEMBLY MULTI- DISPLAY ASSEMBLY OBD FUSE OCCUPANT DETECTION ECU PNK WIRE RADIO RECEIVER ASSEMBLY RED WIRE STEREO COMPONENT AMPLIFIER ASSEMBLY TX- PNK TX+ WIRE VIO WIRE W/ SAFETY CONNECT WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Computer data lines circuit, late production (1 of 4) -> WHT WIRE

wht wiring diagram (114 of 231)

A/C AMPLIFIER ASSEMBLY ACL AIR BAG ECU ASSEMBLY BLK WIRE BLU WIRE BRAKE ACTUATOR ASSEMBLY CANN CANP CERTIFICATION ECU GRN WIRE GRY WIRE LCH LCL LEFT FRONT POWER SEAT SWITCH LEFT HEADLIGHT CONTROL ECU SUB-ASSEMBLY LEFT OUTER MIRROR CONTROL ECU ASSEMBLY LT GRN WIRE MULTIPLEX TILT, TELESCOPIC ECU PARKING BRAKE ECU ASSEMBLY PNK WIRE POWER STEERING ECU ASSEMBLY RED WIRE RIGHT END OF DASH) RIGHT HEADLIGHT CONTROL ECU SUB-ASSEMBLY STEERING SENSOR (SPIRAL CABLE W/ SENSOR SUB-ASSEMBLY) STEREO COMPONENT EQUALIZER ASSEMBLY VIO WIRE W/ MEMORY PNK WIRE W/ POWER TILT, POWER TELESCOPIC W/O POWER TILT, POWER TELESCOPIC WHT WIRE YEL WIRE

Go to component -> Computer data lines circuit, late production (3 of 4) -> WHT WIRE

wht wiring diagram (115 of 231)

ABSORBER CONTROL ECU BLK WIRE BLU WIRE CANN CANP CLEARANCE WARNING ECU ASSEMBLY DRIVING SUPPORT ECU ASSEMBLY FORWARD RECOGNITION CAMERA FRONT TELEVISION CAMERA ASSEMBLY GRN WIRE GRY WIRE LEFT BLIND SPOT MONITOR SENSOR LEFT OUTER REAR VIEW MIRROR ASSEMBLY LEFT SIDE TELEVISION CAMERA ASSEMBLY LT BLU WIRE MAIN BODY ECU MILLIMETER WAVE RADAR SENSOR ASSEMBLY MULTIPLEX NETWORK DOOR ECU PARKING ASSIST ECU PNK WIRE REAR TELEVISION CAMERA ASSEMBLY RED WIRE RIGHT BLIND SPOT MONITOR SENSOR RIGHT END OF DASH) RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY RIGHT OUTER REAR VIEW MIRROR ASSEMBLY RIGHT SIDE TELEVISION CAMERA ASSEMBLY VIO WIRE W/ MEMORY W/ MEMORY W/O MEMORY W/O MEMORY WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Computer data lines circuit, late production (4 of 4) -> WHT WIRE

wht wiring diagram (116 of 231)

BLK WIRE BLK/RED WIRE BLU WIRE BLU/YEL WIRE EARLY PRODUCTION EC+ EC+ EC- EC- PNK +B WIRE ECI+ ECI+ EC- ECU-B 1 FUSE ECU-IG 3 FUSE ENGINE ROOM R/B 2 GARAGE DOOR OPENER GRN WIRE GRY WIRE HOT AT ALL TIMES IB (LEFT END OF DASH) INNER REAR VIEW MIRROR ASSEMBLY INSTRUMENT PANEL J/B ASSEMBLY LATE PRODUCTION LEFT OUTER MIRROR CONTROL ECU ASSEMBLY LT BLU WIRE LT GRN WIRE MAIN BOARD MAP LIGHT ASSEMBLY ORG/ WIRE PNK EC+ WIRE PNK WIRE RED WIRE RELAY ENERGIZED RIGHT END OF DASH) RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY WHT WIRE WHT/BLK WIRE

Go to component -> Electrochromic mirror circuit -> WHT WIRE

wht wiring diagram (117 of 231)

BACK DOOR LOCK ASSEMBLY BLK WIRE CONTROL CIRCUIT COURTESY CTY CTYO D/L 1 FUSE DIODE (COURTESY LIGHT) DOOR LOCK SWITCH ECU-B 3 FUSE FUL FUSE BLOCK ASSEMBLY GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT REAR DOOR LOCK ASSEMBLY LSSR LT BLU WIRE LT GRN WIRE MULTIPLEX NETWORK DOOR ECU MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY ORG/ WIRE PNK WIRE RED WIRE RIGHT REAR DOOR LOCK ASSEMBLY VIO WIRE W/ POWER SEAT W/O POWER BACK DOOR W/ POWER BACK DOOR WHT WIRE WHT/BLK WIRE WIRELESS DOOR LOCK BUZZER YEL WIRE

Go to component -> Forced entry circuit (2 of 7) -> WHT WIRE

wht wiring diagram (118 of 231)

BACK DOOR OPENER SWITCH ASSEMBLY BLK WIRE BLU WIRE CLGB CSEL DATA GRN WIRE INDOOR ELECTRICAL KEY ANTENNA ASSEMBLY 1 INDOOR ELECTRICAL KEY ANTENNA ASSEMBLY 2 INSTRUMENT PANEL J/B ASSEMBLY LEFT FRONT DOOR OUTSIDE HANDLE ASSEMBLY LOCK LT BLU WIRE LT GRN WIRE OLP ORG/ WIRE PNK WIRE RED WIRE RIGHT FRONT DOOR OUTSIDE HANDLE ASSEMBLY STOP LIGHT SWITCH ASSEMBLY WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Forced entry circuit (6 of 7) -> WHT WIRE

wht wiring diagram (119 of 231)

ACC FUSE AUTO AUTO MIRROR FOLDING AWAY SWITCH BLK WIRE BLK/GRN WIRE BLU WIRE COMPUTER DATA LINES SYSTEM DEFOGGER SYSTEM DOWN ECU-IG 2 FUSE EXTERIOR LIGHTS, DEFOGGER SYSTEMS FOLD GRN WIRE GRY WIRE H/L HOT W/ ACC RELAY ENERGIZED INSTRUMENT PANEL J/B ASSEMBLY INTERIOR LCB+ LCV- LEFT LEFT OUTER REAR VIEW MIRROR ASSEMBLY LEFT UP LGND LIGHTS SYSTEM LT GRN WIRE M+ MH MV MR MAIN BODY ECU MIRROR ADJUST SWITCH NAVIGATION SYSTEM ORG/ WIRE OUTER MIRROR SWITCH ASSEMBLY PNK WIRE RED WIRE RELAY ENERGIZED RET RETR RIGHT RIGHT DOWN RTR RTRR SELECT SWITCH TURN HEATER UNFOLD LEFT VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Power mirrors circuit (1 of 2) -> WHT WIRE

wht wiring diagram (120 of 231)

BLK WIRE BLK/GRN WIRE BLU WIRE COMPUTER DATA LINES SYSTEM DEFOGGER SYSTEM ECU-B 3 FUSE ENGINE ROOM R/B 2 EXTERIOR LIGHTS, DEFOGGER SYSTEMS FUSE BLOCK ASSEMBLY GRN WIRE GRY WIRE HEATER HOT AT ALL TIMES HR - LT BLU WIRE LT GRN WIRE M+ MV MIRROR FUSE NAVIGATION SYSTEM PNK WIRE R/B ASSEMBLY RCB+ RCV RED WIRE RGND RIGHT OUTER REAR VIEW MIRROR ASSEMBLY TURN VIO WIRE WHT WIRE WHT/BLK WIRE

Go to component -> Power mirrors circuit (2 of 2) -> WHT WIRE
