Lexus NX Z10 facelift (2017-2021) w/ power seat w/o power seat Wiring diagram
This page shows the only wiring diagram for the component.w/ power seat w/o power seat, which is found in the car Lexus NX Z10 facelift (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ power seat w/o power seat (1 of 1)
A/C AMPLIFIER ASSEMBLY
BENCH TYPE REAR SEAT CUSHION COVER
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ECU-B 2 FUSE
ECU-IG 2 FUSE
ENGINE ROOM R/B 2
FUSE BLOCK ASSEMBLY 2
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL J/B ASSEMBLY
LEFT "C" PILLAR)
LEFT REAR SEAT BACK COVER
LEFT REAR SEAT HEATER CUSHION
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
R/B ASSEMBLY
RED WIRE
REFRESHING SEAT SWITCH
RELAY ENERGIZED
RIGHT END OF DASH)
RIGHT REAR SEAT BACK COVER
RIGHT REAR SEAT HEATER CUSHION
RL/RR SEAT HEATER SWITCH
RLIN
RR S-HTR RELAY
RR S/HTR FUSE
S/HTR R/L FUSE
S/HTR RR FUSE
SEAT HEATER CONTROL
SG-7
SHDE
SHPE
TFAL
TFAR
VIO WIRE
W/ POWER SEAT W/O POWER SEAT
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Rear heated seats circuit -> W/ POWER SEAT W/O POWER SEAT
