Lexus NX Z10 facelift (2017-2021) tx+ cs mscl msch Wiring diagrams
This page contains all the electrical diagrams for the component. tx+ cs mscl msch, in which he is found in the car Lexus NX Z10 facelift (2017-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram tx+ cs mscl msch (1 of 2)
+S CANL
BLK WIRE
BLU WIRE
BRAKE BOOSTER W/ MASTER CYLINDER ASSEMBLY
CAN I/F SPEAKER
CANN
CANP
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DCM FUSE
DISPLAY DRIVER
ENGINE ROOM R/B 1
ENGINE ROOM R/B 2
GRN WIRE
GVIF
HEADUP DISPLAY (COMBINATION METER MIRROR ECU)
HOT AT ALL TIMES
IG+ ES
LED TELLTALES DRIVER
LT GRN WIRE
MCI-
MCO-
MCVD
METER 1 FUSE
MUTE
PNK WIRE
RED WIRE
RIGHT FRONT SPEAKER ASSEMBLY 2
SGND
SHIELD
SPI+
SPO-
TX+ CS MSCL MSCH
USB
USBG
USBV
VIO WIRE
VOR-
VOT+
W/ SAFETY CONNECT
W/O SAFETY CONNECT
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Navigation circuit, early production (5 of 6) -> TX+ CS MSCL MSCH
