Lexus NX Z10 facelift (2017-2021) purge vsv Wiring diagram
This page shows the only wiring diagram for the component.purge vsv, which is found in the car Lexus NX Z10 facelift (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram purge vsv (1 of 1)
Go to component -> Wiring diagram engine performance 2.5l hybrid, engine controls circuit (3 of 6) -> PURGE VSV
