Lexus NX Z10 facelift (2017-2021) power steering ecu assembly Wiring diagrams
This page contains all the electrical diagrams for the component. power steering ecu assembly, in which he is found in the car Lexus NX Z10 facelift (2017-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
power steering ecu assembly wiring diagram (1 of 6)
BLK WIRE
GRN WIRE
HEADUP DISPLAY (COMBINATION METER MIRROR ECU)
HYBRID VEHICLE CONTROL ECU
LEFT HEADLIGHT CONTROL ECU SUB-ASSEMBLY
LT GRN WIRE
PNK WIRE
POWER STEERING ECU ASSEMBLY
RADIO RECEIVER ASSEMBLY
RED WIRE
RIGHT END OF DASH)
STEREO COMPONENT EQUALIZER ASSEMBLY
VIO WIRE
W/ NAVIGATION
W/O NAVIGATION
WHT WIRE
YEL WIRE
Go to component -> Body ecu circuit (3 of 4) -> POWER STEERING ECU ASSEMBLY
power steering ecu assembly wiring diagram (2 of 6)
A/C AMPLIFIER ASSEMBLY
ACL
AIR BAG ECU ASSEMBLY
BLK WIRE
BLU WIRE
BRAKE BOOSTER W/ MASTER CYLINDER ASSEMBLY
CAN (+)
CANN
CANP
CERTIFICATION ECU
GRN WIRE
HYBRID VEHICLE CONTROL ECU
LEFT FRONT POWER SEAT SWITCH
LEFT HEADLIGHT CONTROL ECU SUB-ASSEMBLY
LEFT OUTER MIRROR CONTROL ECU ASSEMBLY
LT GRN WIRE
MULTIPLEX TILT, TELESCOPIC ECU
OPTION CONNECTOR (REMOTE ENGINE STARTER)
PARKING BRAKE ECU ASSEMBLY
PNK WIRE
POWER STEERING ECU ASSEMBLY
RED WIRE
RIGHT END OF DASH)
STEERING SENSOR (SPIRAL CABLE W/ SENSOR SUB-ASSEMBLY)
STEREO COMPONENT EQUALIZER ASSEMBLY
VIO WIRE
W/ ASC
W/ LEXUS ENFORM, SAFETY CONNECT
W/ MEMORY
W/ POWER TILT, POWER TELESCOPIC W/O POWER TILT, POWER TELESCOPIC
WHT WIRE
YEL WIRE
Go to component -> Computer data lines circuit, early production (2 of 3) -> POWER STEERING ECU ASSEMBLY
power steering ecu assembly wiring diagram (3 of 6)
BLK WIRE
BLU WIRE
CAN JUNCTION TERMINAL 2
CANN
CANP
GRN WIRE
LCH
LCL
LEFT FRONT POWER SEAT SWITCH
LEFT HEADLIGHT CONTROL ECU SUB-ASSEMBLY
LEFT OUTER MIRROR CONTROL ECU ASSEMBLY
LT GRN WIRE
MULTIPLEX NETWORK DOOR ECU
MULTIPLEX TILT, TELESCOPIC ECU
PARKING BRAKE ECU ASSEMBLY
PNK WIRE
POWER STEERING ECU ASSEMBLY
RED WIRE
STEERING SENSOR (SPIRAL CABLE W/ SENSOR SUB-ASSEMBLY)
VIO WIRE
W/ ADAPTIVE FRONT LIGHTING SYSTEM
W/ POWER TILT, POWER TELESCOPIC W/O POWER TILT, POWER TELESCOPIC
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Computer data lines circuit, late production (2 of 5) -> POWER STEERING ECU ASSEMBLY
power steering ecu assembly wiring diagram (4 of 6)
A/C AMPLIFIER ASSEMBLY
ACL
AIR BAG ECU ASSEMBLY
BLK WIRE
BLU WIRE
BRAKE ACTUATOR ASSEMBLY
CANN
CANP
CERTIFICATION ECU
GRN WIRE
GRY WIRE
LCH
LCL
LEFT FRONT POWER SEAT SWITCH
LEFT HEADLIGHT CONTROL ECU SUB-ASSEMBLY
LEFT OUTER MIRROR CONTROL ECU ASSEMBLY
LT GRN WIRE
MULTIPLEX TILT, TELESCOPIC ECU
PARKING BRAKE ECU ASSEMBLY
PNK WIRE
POWER STEERING ECU ASSEMBLY
RED WIRE
RIGHT END OF DASH)
RIGHT HEADLIGHT CONTROL ECU SUB-ASSEMBLY
STEERING SENSOR (SPIRAL CABLE W/ SENSOR SUB-ASSEMBLY)
STEREO COMPONENT EQUALIZER ASSEMBLY
VIO WIRE
W/ MEMORY PNK WIRE
W/ POWER TILT, POWER TELESCOPIC W/O POWER TILT, POWER TELESCOPIC
WHT WIRE
YEL WIRE
Go to component -> Computer data lines circuit, late production (3 of 4) -> POWER STEERING ECU ASSEMBLY
power steering ecu assembly wiring diagram (5 of 6)
BLK WIRE
BLU WIRE
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISPLAY DRIVER
ECU- IG 6 FUSE
ECU-B 4 FUSE
ELECTRIC POWER STEERING COLUMN SUB-ASSEMBLY
ENGINE ROOM R/B 1
ENGINE ROOM R/B 2
EPS FUSE
EPS-IG FUSE
GRN WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL J/B ASSEMBLY
LED DRIVER
LT BLU WIRE
LT GRN WIRE
MAIN RELAY ENERGIZED
METER 1 FUSE
METER 2 FUSE
ORG/ WIRE
PNK WIRE
POWER STEERING ECU ASSEMBLY
RED WIRE
RELAY ENERGIZED
SPEAKER
STEERING SENSOR (SPIRAL CABLE W/ SENSOR SUB-ASSEMBLY)
TELLTALES
TORQUE SENSOR
VIO WIRE
W/ POWER TILT, TELESCOPIC W/O POWER TILT, TELESCOPIC
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Electronic power steering circuit -> POWER STEERING ECU ASSEMBLY
power steering ecu assembly wiring diagram (6 of 6)
BATTERY
BATTERY VOLTAGE SENSOR
BLK WIRE
BLK/GRY WIRE
BRN WIRE
FOLD SEAT SWITCH ASSEMBLY 2
HYBRID BATTERY JUNCTION BLOCK ASSEMBLY
INTER LOCK SWITCH
OCCUPANT DETECTION ECU
PA (RIGHT "B" PILLAR)
PARKING ASSIST ECU
PB (RIGHT "C" PILLAR)
POWER STEERING ECU ASSEMBLY
PPL PNK WIRE
RIGHT BATTERY COOLING BLOWER ASSEMBLY
RIGHT BLIND SPOT MONITOR SENSOR
RIGHT FRONT POWER SEAT SWITCH
RIGHT FRONT SEAT INNER BELT ASSEMBLY
RIGHT REAR COMBINATION LIGHT ASSEMBLY
RIGHT REAR DOOR LOCK ASSEMBLY
RIGHT REAR DOOR OUTSIDE HANDLE ASSEMBLY
RIGHT REAR POWER SEAT SWITCH
RIGHT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY
RIGHT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY
RIGHT SEAT CUSHION CLIMATE CONTROL BLOWER ASSEMBLY
RIGHT SEAT HEATER CONTROL SUB-ASSEMBLY
STEREO COMPONENT AMPLIFIER ASSEMBLY
THEFT WARNING SIREN ASSEMBLY
VIO WIRE
W/ CLIMATE CONTROL SEAT
W/ NAVIGATION
W/ SEAT HEATER
W/O CLIMATE CONTROL SEAT, SEAT HEATER W/ SEAT HEATER
W/O NAVIGATION
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (5 of 7) -> POWER STEERING ECU ASSEMBLY
