Lexus NX Z10 facelift (2017-2021) main relay energized Wiring diagrams
This page contains all the electrical diagrams for the component. main relay energized, in which he is found in the car Lexus NX Z10 facelift (2017-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram main relay energized (1 of 7)
ACC FUSE
BKUP LP FUSE
BLK WIRE
BLU WIRE
CAN I/F SPEAKER
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DIODE (SHIFT POSITION)
DISPLAY DRIVER
GRN WIRE
HOT AT ALL TIMES
HOT W/
HOT W/ ACC RELAY ENERGIZED
IG+ ES
INSTRUMENT PANEL J/B ASSEMBLY
LED DRIVER
LT GRN WIRE
MAIN RELAY ENERGIZED
METER 2 FUSE
MULTI- FUNCTION INDICATOR LAMP
PARK/NEUTRAL POSITION SWITCH ASSEMBLY
PNK WIRE
RED WIRE
STARTING/ CHARGING SYSTEM
STOP FUSE
TELLTALES
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> A/t circuit (3 of 4) -> MAIN RELAY ENERGIZED
Wiring diagram main relay energized (2 of 7)
ACC FUSE
BLK WIRE
BLU WIRE
CAXH
CAXL
CAYH
CAYL
COMBINATION METER ASSEMBLY
ECU-B 2 FUSE
ECU-IG 2 FUSE
ENGINE ROOM R/B 2
GRN WIRE
HEADUP DISPLAY (COMBINATION METER MIRROR ECU)
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED
INSTRUMENT PANEL J/B ASSEMBLY
LT BLU WIRE
LT GRN WIRE
MAIN RELAY ENERGIZED
MO-
MSCH
MSCL
NETWORK GATEWAY ECU
ORG/ WIRE
PNK WIRE
RED WIRE
RELAY ENERGIZED
REMOTE OPERATION CONTROLLER ASSEMBLY
RIGHT END OF DASH)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Computer data lines circuit, late production (2 of 4) -> MAIN RELAY ENERGIZED
Wiring diagram main relay energized (3 of 7)
ACC FUSE
ACL
AIR BAG ECU ASSEMBLY
BLK WIRE
BLU WIRE
CERTIFICATION ECU
CLEARANCE WARNING ECU ASSEMBLY
COMBINATION METER ASSEMBLY
DRIVING SUPPORT ECU ASSEMBLY
ECU-IG 2 FUSE
GRN WIRE
HEADUP DISPLAY (COMBINATION METER MIRROR ECU)
HOT W/
HOT W/ ACC RELAY ENERGIZED
HYBRID VEHICLE CONTROL ECU (LOWER RIGHT SIDE OF DASH)
INSTRUMENT PANEL J/B ASSEMBLY
LT BLU WIRE
LT GRN WIRE
MAIN RELAY ENERGIZED
MILLIMETER WAVE RADAR SENSOR ASSEMBLY
ORG/ WIRE
PNK WIRE
RED WIRE
RIGHT END OF DASH)
STEREO COMPONENT EQUALIZER ASSEMBLY
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Computer data lines circuit, late production (4 of 5) -> MAIN RELAY ENERGIZED
Wiring diagram main relay energized (4 of 7)
BLK WIRE
BLU WIRE
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISPLAY DRIVER
ECU- IG 6 FUSE
ECU-B 4 FUSE
ELECTRIC POWER STEERING COLUMN SUB-ASSEMBLY
ENGINE ROOM R/B 1
ENGINE ROOM R/B 2
EPS FUSE
EPS-IG FUSE
GRN WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL J/B ASSEMBLY
LED DRIVER
LT BLU WIRE
LT GRN WIRE
MAIN RELAY ENERGIZED
METER 1 FUSE
METER 2 FUSE
ORG/ WIRE
PNK WIRE
POWER STEERING ECU ASSEMBLY
RED WIRE
RELAY ENERGIZED
SPEAKER
STEERING SENSOR (SPIRAL CABLE W/ SENSOR SUB-ASSEMBLY)
TELLTALES
TORQUE SENSOR
VIO WIRE
W/ POWER TILT, TELESCOPIC W/O POWER TILT, TELESCOPIC
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Electronic power steering circuit -> MAIN RELAY ENERGIZED
Wiring diagram main relay energized (5 of 7)
A/BAG FUSE
ABFS
BLK WIRE
BLU WIRE
BSW
BUCKLE SWITCH
COMPUTER DATA LINES SYSTEM
DCM (TELEMATICS TRANSCEIVER)
DIA
FSR- PNK BGND WIRE
GRN WIRE
GRY WIRE
GSW
HYBRID VEHICLE CONTROL ECU
INSTRUMENT PANEL J/B ASSEMBLY
LEFT FRONT AIR BAG SENSOR
LEFT FRONT OCCUPANT CLASSIFICATION SENSOR
LEFT REAR OCCUPANT CLASSIFICATION SENSOR
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU
MAIN RELAY ENERGIZED
OCCUPANT DETECTION ECU
PASSIVE RESTRAINTS SYSTEM
PNK WIRE
RED WIRE
RIGHT FRONT AIR BAG SENSOR
RIGHT FRONT SEAT INNER BELT ASSEMBLY
SGD
SIG
SL-
SR-
SVC
W/ LEXUS ENFORM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (2 of 3) -> MAIN RELAY ENERGIZED
Wiring diagram main relay energized (6 of 7)
AIR BAG ECU ASSEMBLY
BBR+
BCR+
BDR
BLK WIRE
BLU WIRE
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
ENGINE ROOM R/B 2
FCP+
GRN WIRE
HOT AT ALL TIMES
ICR+
INSTRUMENT PANEL J/B ASSEMBLY
LED DRIVER
MAIN RELAY ENERGIZED
METER 2 FUSE
ODS FUSE
PASSIVE RESTRAINTS SYSTEM
PNK WIRE
PR-
PRETENSIONER
RED WIRE
RIGHT CURTAIN SHIELD AIR BAG ASSEMBLY
RIGHT DOOR SIDE AIR BAG SENSOR
RIGHT FRONT SEAT AIR BAG ASSEMBLY
RIGHT FRONT SEAT CUSHION AIR BAG ASSEMBLY
RIGHT FRONT SEAT OUTER BELT ASSEMBLY
RIGHT SIDE AIR BAG SENSOR ASSEMBLY
SFR-
TELLTALES
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Supplemental restraints circuit (3 of 3) -> MAIN RELAY ENERGIZED
Wiring diagram main relay energized (7 of 7)
ACC FUSE
ANTENNA CORD SUB-ASSEMBLY
BLK WIRE
BLU WIRE
CANN
CANP
COMPUTER DATA LINES SYSTEM
DCM (TELEMATICS TRANSCEIVER)
DCM FUSE
ENGINE ROOM R/B 2
GPS ANTENNA
GRN WIRE
GSW
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED
INSTRUMENT PANEL J/B ASSEMBLY
LT BLU WIRE
LT GRN WIRE
MAIN BOARD
MAIN RELAY ENERGIZED
MCI-
MCO-
MCVD
MIN
MUTE
NAVIGATION ECU
NCA WIRE
ORG/ WIRE
PNK WIRE
RADIO RECEIVER ASSEMBLY
RED WIRE
SGND
SHIELD
SIG
SLED
SLPD
SPI+
SPO-
TEL
TELEPHONE ANTENNA
TELEPHONE MICROPHONE ASSEMBLY
USB
USBG
USBS
USBV
VIO WIRE
VOR-
VOT+
W/ NAVIGATION
W/O NAVIGATION
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Telematics circuit, late production (1 of 2) -> MAIN RELAY ENERGIZED
