Lexus NX Z10 facelift (2017-2021) left turn left lane change neutral right lane change right turn 1) 2) 3) 4) 5) Wiring diagram
This page shows the only wiring diagram for the component.left turn left lane change neutral right lane change right turn 1) 2) 3) 4) 5), which is found in the car Lexus NX Z10 facelift (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left turn left lane change neutral right lane change right turn 1) 2) 3) 4) 5) (1 of 1)
BLK WIRE
BLU WIRE
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISPLAY DRIVER
DRIVING SUPPORT ECU ASSEMBLY
ECU- IG 1 FUSE
ECU-IG 2 FUSE
GRN WIRE
GRY WIRE
HEADLIGHT DIMMER SWITCH ASSEMBLY
IGB
INSTRUMENT PANEL J/B ASSEMBLY
LANE DEPARTURE WARNING
LANE DEPARTURE WARNING CAMERA
LEFT TURN LEFT LANE CHANGE NEUTRAL RIGHT LANE CHANGE RIGHT TURN 1) 2) 3) 4) 5)
LKSW
LT BLU WIRE
METER 2 FUSE
MILLIMETER WAVE RADAR SENSOR ASSEMBLY
PNK SPSW WIRE
PNK WIRE
RED WIRE
RELAY ENERGIZED
RIGHT END OF DASH)
RIGHT STEERING PAD SWITCH STEERING PAD SWITCH ASSEMBLY
SKID CONTROL BUZZER ASSEMBLY
SPIRAL CABLE W/ SENSOR SUB-ASSEMBLY
TURN SWITCH
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Lane departure warning circuit, early production -> LEFT TURN LEFT LANE CHANGE NEUTRAL RIGHT LANE CHANGE RIGHT TURN 1) 2) 3) 4) 5)
