Lexus NX Z10 facelift (2017-2021) front fog right fog light assembly Wiring diagram
This page shows the only wiring diagram for the component.front fog right fog light assembly, which is found in the car Lexus NX Z10 facelift (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front fog right fog light assembly (1 of 1)
BLK WIRE
BLU WIRE
DRL FUSE
DRL LH RELAY
DRL RH RELAY
ENGINE ROOM R/B 2
FOG FR FUSE
FOG FR RELAY
FRONT FOG LEFT FOG LIGHT ASSEMBLY
FRONT FOG RIGHT FOG LIGHT ASSEMBLY
GRN WIRE
H-LP LH LO FUSE
H-LP LO RELAY
H-LP RH/ H-LP RH-LO FUSE
HOT AT ALL TIMES
LEFT HEADLIGHT ASSEMBLY
PNK WIRE
RED WIRE
RIGHT HEADLIGHT ASSEMBLY
SOL +
VIO WIRE
W/O CORNERING LIGHT W/ CORNERING LIGHT
WHT WIRE
YEL WIRE
Go to component -> Headlights circuit, w/o headlight beam level (2 of 3) -> FRONT FOG RIGHT FOG LIGHT ASSEMBLY
