Lexus NX Z10 facelift (2017-2021) eco switch Wiring diagram
This page shows the only wiring diagram for the component.eco switch, which is found in the car Lexus NX Z10 facelift (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram eco switch (1 of 1)
A/C AMPLIFIER ASSEMBLY
BLK WIRE
BLU WIRE
BLW
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
ECO SWITCH
ECOS
ECU- IG 1 FUSE
ECU-IG 3 FUSE
ENGINE ROOM R/B 2
FDEF
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IDH
INSTRUMENT PANEL J/B ASSEMBLY
INTEGRATION CONTROL, PANEL ASSEMBLY
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PTC HTR 1 FUSE
PTC HTR 1 RELAY
PTC HTR 2 FUSE
PTC HTR 2 RELAY
PTC HTR 3 FUSE
PTC HTR 3 RELAY
QUICK HEATER ASSEMBLY
RDFG
RED WIRE
RELAY ENERGIZED
SEATS SYSTEM
SG-1
SG-2
SG-5
SHD
SHDE
SHP+
SHPE
TAM
TFG
TNG
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (1 of 4) -> ECO SWITCH
