Lexus NX Z10 facelift (2017-2021) a/c w/ pmp relay Wiring diagram
This page shows the only wiring diagram for the component.a/c w/ pmp relay, which is found in the car Lexus NX Z10 facelift (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram a/c w/ pmp relay (1 of 1)
A/C W/ PMP FUSE
A/C W/ PMP RELAY
ACPB
ACPE
AIR CONDITIONING THERMISTOR ASSEMBLY
BLK WIRE
BLOWER MOTOR W/ FAN SUB-ASSEMBLY
BLU WIRE
CLK+
COMPRESSOR W/ MOTOR ASSEMBLY
COMPUTER DATA LINES SYSTEM
COOLER THERMISTOR (ROOM TEMPERATURE SENSOR)
DIN
DOUT
EARLY PRODUCTION
ECU-B 2 FUSE
ENGINE ROOM R/B 2
ETI
GRN WIRE
GRY WIRE
HEATER ACCESSORY ASSEMBLY
HOT AT ALL TIMES
HTR FUSE
HYBRID VEHICLE CONTROL ECU
IDH
INVERTER W/ CONVERTER ASSEMBLY
ITE
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
ORG/BLK WIRE
ORG/WHT WIRE
PNK WIRE
RED WIRE
SHIELD
STB
STBI
TFG
TNG
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (2 of 4) -> A/C W/ PMP RELAY
