Fuel door release circuit for Lexus NX Z10 (2014-2017)
Fuel door release circuit
BLU WIRE
COMPUTER DATA LINES SYSTEM
EFI 2 FUSE
ENGINE ROOM R/B 1
FREL
FUEL
FUEL LID LOCK W/ MOTOR ASSEMBLY
FUEL LID OPENER SWITCH
FUEL OPN 1 FUSE
FUEL OPN 2 FUSE
FUEL OPN RELAY
GRN WIRE
HOT AT ALL TIMES
HOT W/ EFI-MAIN 1 RELAY ENERGIZED
HYBRID W/ FUEL VAPOR CONTAINMENT
HYBRID W/O FUEL VAPOR CONTAINMENT, EXCEPT HYBRID
INTEGRATION CONTROL, PANEL ASSEMBLY
LIDO
LT BLU WIRE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
PPL
PPL/GRN WIRE
PPL/RED WIRE
PPL/VIO WIRE
PPL/WHT WIRE
WHT WIRE
