Rear folding seat circuit for Lexus NX Z10 (2014-2017)

BACK BLK WIRE BLU WIRE BRN WIRE ECU-DCC 2 FUSE ENGINE ROOM R/B 1 ENGINE ROOM R/B 2 FDL+ FOLD SEAT CONTROL ECU GA (RIGHT "B" PILLAR) GRN WIRE GRY WIRE HLG HLS HOT AT ALL TIMES LCKF LCKR LS+ LT BLU WIRE LT GRN WIRE P/SEAT (RR) FUSE P/SEAT R/L FUSE PNK WIRE PPL PPL/BLK WIRE PPL/GRN WIRE PPL/LT BLU WIRE PPL/RED WIRE PPL/VIO WIRE RCL- RED WIRE RIGHT BACK LOCK LIMIT SWITCH (RIGHT REAR SEATBACK LOCK ASSEMBLY) RIGHT BACK LOCK RELEASE MOTOR (RIGHT REAR SEAT LOCK CONTROL LEVER SUB-ASSEMBLY) RIGHT END OF DASH) RIGHT REAR SEAT RIGHT REAR SEATBACK LOCK ASSEMBLY RTNR SRCL TMC MADE TMMC MADE VIO WIRE WHT WIRE WHT/BLK WIRE

BACK BLK WIRE BLU WIRE BRN WIRE ECUB FOLD FOLD SEAT CONTROL ECU FOLD SEAT SWITCH ASSEMBLY GRN WIRE GRY WIRE HLG HLS ILL LEFT BACK LOCK LIMIT SWITCH (LEFT REAR SEATBACK LOCK ASSEMBLY) LEFT BACK LOCK RELEASE MOTOR (LEFT REAR SEAT LOCK CONTROL LEVER SUB-ASSEMBLY) LEFT FRONT POSITION CONTROL ECU ASSEMBLY LEFT REAR POWER SEAT SWITCH LEFT REAR SEAT LEFT REAR SEATBACK LOCK ASSEMBLY LS+ LT BLU WIRE LT GRN WIRE MPX PNK WIRE PPL PPL/BLU WIRE PPL/GRN WIRE PPL/LT BLU WIRE PPL/LT GRN WIRE PPL/ORG WIRE RED WIRE RIGHT REAR POWER SEAT SWITCH RTNL RTRN SYSG TMC MADE TMMC MADE VIO WIRE WHT/BLK WIRE
