Lexus NX Z10 (2014-2017) wireless door lock buzzer Wiring diagrams

This page contains all the electrical diagrams for the component. wireless door lock buzzer, in which he is found in the car Lexus NX Z10 (2014-2017). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram wireless door lock buzzer (1 of 2)

Wiring diagram wireless door lock buzzer for Lexus NX Z10 (2014-2017)

Get access

2.5L 2.4L TURBO, 2.5L HYBRID 2.5L HYBRID 2.5L, 2.4L TURBO AIR FUEL RATIO SENSOR 2 SHIELD AIR FUEL RATIO SENSOR SHIELD CAM TIMING OIL CONTROL MOTOR W/ EDU ASSEMBLY COMPRESSOR W/ MAGNET CLUTCH ASSEMBLY ELECTRIC WATER PUMP ASSEMBLY ENGINE ROOM R/B 1 EXCEPT 2.4L TURBO FAN W/ MOTOR ASSEMBLY FUEL INJECTOR ASSEMBLY 1 (FOR DIRECT INJECTION) SHIELD FUEL INJECTOR ASSEMBLY 2 (FOR DIRECT INJECTION) SHIELD FUEL INJECTOR ASSEMBLY 3 (FOR DIRECT INJECTION) SHIELD FUEL INJECTOR ASSEMBLY 4 (FOR DIRECT INJECTION) SHIELD FUEL PUMP ASSEMBLY SHIELD IGNITION COIL ASSEMBLY 1 IGNITION COIL ASSEMBLY 2 IGNITION COIL ASSEMBLY 3 IGNITION COIL ASSEMBLY 4 INVERTER W/ CONVERTER ASSEMBLY KNOCK CONTROL SENSOR SHIELD LEFT FOG LIGHT ASSEMBLY LEFT FRONT TURN SIGNAL LIGHT LEFT HEADLIGHT ECU SUB-ASSEMBLY 1 LEFT HEADLIGHT UNIT ASSEMBLY LEFT SPOT LIGHT ASSEMBLY OIL PUMP ASSEMBLY PPL RIGHT FOG LIGHT ASSEMBLY RIGHT SPOT LIGHT ASSEMBLY SEMICONDUCTOR POWER INTEGRATION ECU SHIELD SHIFT CONTROL ACTUATOR ASSEMBLY VEHICLE APPROACHING SPEAKER CONTROL W/ CORNERING LIGHT W/O HEADLIGHT BEAM LEVEL CONTROL WHT/BLK WIRE WINDSHIELD WIPER RELAY ASSEMBLY WIPER RELAY WIRELESS DOOR LOCK BUZZER

Go to component: -> Ground distribution circuit (3 of 8) -> WIRELESS DOOR LOCK BUZZER

Wiring diagram wireless door lock buzzer (2 of 2)

Wiring diagram wireless door lock buzzer for Lexus NX Z10 (2014-2017)

Get access

BBC 2 FUSE BIN 2 BLK WIRE BLU WIRE BZR CAN I/F CAN L CLS COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM DISPLAY DRIVER DOWN DRIVER'S DOOR DWN ECU-B 2 FUSE ECU-IGR 2 FUSE ENGINE ROOM R/B 1 ENGINE STOP, START ECU FRONT ROOF SUNSHADE ECU (SLIDING ROOF DRIVE GEAR ASSEMBLY) GLASS ROOF CLOSE GLASS ROOF OPEN GLASS ROOF VENT GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ HOT W/ IGR 1 RELAY ENERGIZED IGR ILLB LEFT FRONT COURTESY LIGHT ASSEMBLY LEFT FRONT DOOR LOCK W/ MOTOR ASSEMBLY LILL LIN 2 LT BLU WIRE LT GRN WIRE MAIN BOARD MAIN BODY ECU MAP LIGHT SUB-ASSEMBLY METER-IGR FUSE MPX 1 MPX 2 OPN PNK MPX 1 WIRE PNK SW WIRE PNK WIRE POWER DISTRIBUTION BOX ASSEMBLY POWER DISTRIBUTION SYSTEM PPL PPL/BLK WIRE PPL/GRN WIRE PPL/LT GRN WIRE PPL/VIO WIRE RED WIRE S ROOF FUSE SHADE CLOSE SHADE OPEN SLIDING ROOF CONTROL ECU (SLIDING ROOF DRIVE GEAR SUB-ASSEMBLY) TILT VIO WIRE W/ SLIDING ROOF W/ STOP/ START SYSTEM W/O STOP/ START SYSTEM WHT WIRE WHT/BLK WIRE WIRELESS DOOR LOCK BUZZER

Go to component: -> Power top/sunroof circuit -> WIRELESS DOOR LOCK BUZZER
