Lexus NX Z10 (2014-2017) vvt relay Wiring diagrams
This page contains all the electrical diagrams for the component. vvt relay, in which he is found in the car Lexus NX Z10 (2014-2017). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
vvt relay wiring diagram (1 of 3)
2.5L
2.5L HYBRID
2.5L, 2.4L TURBO
BATTERY (2.5L HYBRID)
BLK WIRE
BLK/DK GRN WIRE
BRAKE LEVEL WARNING SWITCH (BRAKE MASTER CYLINDER RESERVOIR ASSEMBLY)
BRAKE PEDAL STROKE SENSOR ASSEMBLY
BRN WIRE
EFI MAIN RELAY 2
EFI- MAIN RELAY 3
ENGINE STOP, START ECU
HEATER ACCESSORY ASSEMBLY
HOOD COURTESY SWITCH (HOOD LOCK ASSEMBLY)
IGCT RELAY
IGP RELAY 1
INJ RELAY
JB JA
KICK DOOR CONTROL SENSOR
LEFT FRONT SIDE RADAR SENSOR
LEVEL WARNING SWITCH ASSEMBLY
MILLIMETER WAVE RADAR SENSOR ASSEMBLY
OIL PMP RELAY
PPL
RADIO SETTING CONDENSER
RIGHT FRONT SIDE RADAR SENSOR
SEMICONDUCTOR POWER INTEGRATION ECU
SHIFT CONTROL ACTUATOR ASSEMBLY
ST RELAY 1
STOP LIGHT SWITCH ASSEMBLY
VVT RELAY
WHT/BLK WIRE
WINDSHIELD WIPER RELAY ASSEMBLY
Go to component -> Ground distribution circuit (1 of 8) -> VVT RELAY
vvt relay wiring diagram (2 of 3)
2.5L
2.5L HYBRID
2.5L, 2.4L TURBO W/O TELEMATICS SYSTEM
ABS 3 FUSE
AIR CONDITIONING AMPLIFIER ASSEMBLY
BLK WIRE
BLU WIRE
BRAKE BOOSTER CONTROL ECU (BRAKE BOOSTER W/ MASTER CYLINDER ASSEMBLY)
COMPRESSOR W/ MOTOR ASSEMBLY
D INJ FUSE
D INJ RELAY
DEICER RELAY
ECU- IGP 1 FUSE
ECU- IGP 2 FUSE
ECU-IGP 3 FUSE
EFI MAIN RELAY 2
EFI- MAIN 1 FUSE
EFI- MAIN 1 RELAY
EFI- MAIN 2 FUSE
EFI- MAIN 3 FUSE
EFI- MAIN RELAY 3
ENGINE ROOM R/B 2
ENGINE STOP, START ECU
EPS FUSE
FROM EFI 1 FUSE (DIAGRAM 3 OF 10)
FUEL INJECTOR ASSEMBLY 1 (PORT INJECTION)
FUEL INJECTOR ASSEMBLY 2 (PORT INJECTION)
FUEL INJECTOR ASSEMBLY 3 (PORT INJECTION)
FUEL INJECTOR ASSEMBLY 4 (PORT INJECTION)
GRN WIRE
GRY WIRE
HYBRID VEHICLE CONTROL ECU
IGCT RELAY
IGNITION COIL ASSEMBLY 1
IGNITION COIL ASSEMBLY 2
IGNITION COIL ASSEMBLY 3
IGNITION COIL ASSEMBLY 4
IGP 1 RELAY
IGP- MAIN 1 FUSE
IGPT-IG FUSE
INJ FUSE
INV W/PMP 2 FUSE
INV W/PMP RELAY
LT BLU WIRE
LT GRN WIRE
NETWORK GATEWAY ECU
OIL PMP FUSE
OIL PMP RELAY
ORG/ WIRE
P/I FUSE
PNK WIRE
POWER STEERING ECU (RACK, PINION POWER STEERING GEAR ASSEMBLY)
PPL
PPL/BLK WIRE
PPL/BLU WIRE
PPL/GRN WIRE
PPL/LT GRN WIRE
PPL/PNK WIRE
PTC HTR 1 RELAY
PTC HTR 2 RELAY
REAR SEAT HEATER SWITCH
RED WIRE
S/HTR 2 RELAY
SEMICONDUCTOR POWER INTEGRATION ECU
SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY)
STEREO COMPONENT EQUALIZER ASSEMBLY
STOP LIGHT SWITCH ASSEMBLY
TO INSTRUMENT PANEL R/B 2 (DIAGRAM 2 OF 10)
TO POWER DISTRIBUTION BOX ASSEMBLY (DIAGRAM 10 OF 10)
TRANSMISSION FLOOR SHIFT ASSEMBLY
VIO WIRE
VVT FUSE
VVT RELAY
W/ TELEMATICS SYSTEM
WASHER FUSE
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WIPER RELAY ASSEMBLY
Go to component -> Power distribution circuit (4 of 10) -> VVT RELAY
vvt relay wiring diagram (3 of 3)
BLK WIRE
BLU WIRE
BRN WIRE
EFI 4 FUSE
EFI 8 FUSE
EFI MAIN RELAY 1
EFI MAIN RELAY 2
EFI- MAIN 1 FUSE
EFI- MAIN 2 FUSE
EFI- MAIN 3 FUSE
EFI- MAIN RELAY 3
ENGINE ROOM R/B 1
FUEL PRESSURE SENSOR (HIGH PRESSURE SIDE)
FUEL PRESSURE SENSOR (LOW PRESSURE SIDE)
GRN WIRE
HOT AT ALL TIMES
INTAKE MASS AIR FLOW METER SUB-ASSEMBLY
KNOCK CONTROL SENSOR
LT GRN WIRE
OIL PRESSURE/ TEMPERATURE SENSOR
ORG/ WIRE
PFL
PNK WIRE
RED WIRE
SHIELD
THA
TOUT
VCC
VIO WIRE
VVT FUSE
VVT RELAY
WHT WIRE
WHT/BLK WIRE
Go to component -> Wiring diagram engine performance 2.5l (4 of 10) -> VVT RELAY
