Lexus NX Z10 (2014-2017) view switch Wiring diagrams

This page contains all the electrical diagrams for the component. view switch, in which he is found in the car Lexus NX Z10 (2014-2017). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram view switch (1 of 2)

Wiring diagram view switch for Lexus NX Z10 (2014-2017)

Get access

BLK WIRE BLU WIRE BRN WIRE ECU-IGR 1 FUSE ENGINE CONTROLS SYSTEM FUEL LID OPENER SWITCH HOT AT ALL TIMES INTEGRATION CONTROL, PANEL ASSEMBLY NAVIGATION SYSTEM PARKING SUPPORT SWITCH PBD SWITCH POWER DISTRIBUTION BOX ASSEMBLY PPL PPL DB PPL/BLK WIRE PPL/BLU WIRE PPL/LT GRN WIRE PPL/RED WIRE PPL/VIO WIRE VIEW SWITCH VIO WIRE WARNING SYSTEMS

Go to component: -> Integration control and panel circuit -> VIEW SWITCH

Wiring diagram view switch (2 of 2)

Wiring diagram view switch for Lexus NX Z10 (2014-2017)

Get access

BCB+ BCV- BGND BLK WIRE BLSW BLU WIRE BRN WIRE BTL BTR CB+ CGND COMPUTER DATA LINES SYSTEM CV+ ECU- DCC 3 FUSE ECU-IGR 3 FUSE FRONT TELEVISION CAMERA ASSEMBLY GB+ GGND GOV+ GRN WIRE GTL GTR GVO+ HOT AT ALL TIMES HOT W/ IGR 2 RELAY ENERGIZED INTEGRATION CONTROL, PANEL ASSEMBLY LCB+ LCV- LEFT OUTER REAR VIEW MIRROR ASSEMBLY LGND NCA WIRE PARKING ASSIST ECU PNK WIRE POWER DISTRIBUTION BOX ASSEMBLY PPL PPL/BLK WIRE PPL/BLU WIRE PPL/LT GRN WIRE PPL/RED WIRE PPL/VIO WIRE RCB+ RCV REAR TELEVISION CAMERA ASSEMBLY RED WIRE REV RGND SGND SHIELD SIDE CAMERA RIGHT SIDE TELEVISION CAMERA ASSEMBLY VIEW SWITCH VIO WIRE WHT WIRE

Go to component: -> Telematics circuit (1 of 2) -> VIEW SWITCH
