Lexus NX Z10 (2014-2017) vacuum regulating valve assembly Wiring diagram
This page shows the only wiring diagram for the component.vacuum regulating valve assembly, which is found in the car Lexus NX Z10 (2014-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vacuum regulating valve assembly (1 of 1)
AIR FUEL RATIO SENSOR
BLK WIRE
BLU WIRE
D INJ FUSE
D INJ RELAY
ECM (LEFT SIDE OF ENGINE COMPT)
EDU 1 FUSE
EDU 2 FUSE
EDU 3 FUSE
EDU 4 FUSE
EFCV
ENGINE ROOM R/B 1
EPEO
EPIM
FCA
FUEL INJECTOR ASSEMBLY 4 (DIRECT INJECTION)
FUEL PRESSURE SENSOR (HIGH PRESSURE SIDE)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT GRN WIRE
NCA WIRE
NE+
ORG/ WIRE
PEO
PIM
PNK WIRE
RED WIRE
THA
THEO
THIM
VACUUM REGULATING VALVE ASSEMBLY
VCFV
VCPR
VCVG
VIO WIRE
VPR
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component: -> Wiring diagram engine performance 2.4l turbo (6 of 9) -> VACUUM REGULATING VALVE ASSEMBLY
