Lexus NX Z10 (2014-2017) throttle body w/ throttle position sensor assembly Wiring diagrams

This page contains all the electrical diagrams for the component. throttle body w/ throttle position sensor assembly, in which he is found in the car Lexus NX Z10 (2014-2017). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram throttle body w/ throttle position sensor assembly (1 of 3)

Wiring diagram throttle body w/ throttle position sensor assembly for Lexus NX Z10 (2014-2017)

Get access

ACCELERATOR PEDAL W/ SENSOR ROD ASSEMBLY BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM ECCS ECU-IGP 3 FUSE EFI- MAIN 1 FUSE EFI- MAIN 1 RELAY EFI-B 1 FUSE EFI-B 2 FUSE ENGINE CONTROLS SYSTEM ENGINE ROOM R/B 1 ETHO GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGP 1 RELAY ENERGIZED LT BLU WIRE LT GRN WIRE NCB NCO NTB NTO P CON MAIN FUSE PNK WIRE POWER DISTRIBUTION SYSTEM PPL PPL/BLK WIRE PPL/BRN WIRE PPL/GRN WIRE PPL/LT GRN WIRE PPL/PNK WIRE RED WIRE SBFS SFTD SFTU SLT- SLU+ THROTTLE BODY W/ THROTTLE POSITION SENSOR ASSEMBLY VIO WIRE WHT WIRE

Go to component: -> A/t circuit (1 of 3) -> THROTTLE BODY W/ THROTTLE POSITION SENSOR ASSEMBLY

Wiring diagram throttle body w/ throttle position sensor assembly (2 of 3)

Wiring diagram throttle body w/ throttle position sensor assembly for Lexus NX Z10 (2014-2017)

Get access

2.5L ABS 2 FUSE ACCELERATOR PEDAL W/ SENSOR ROD ASSEMBLY BIN 2 BLK WIRE BLU WIRE CAN I/F CERTIFICATION ECU COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM DISPLAY DRIVER EFI 1 FUSE ENGINE ROOM R/B 1 GRN WIRE GRY WIRE HOT AT ALL TIMES LED DRIVER LT BLU WIRE PNK WIRE PPL PPL/BLK WIRE PPL/GRN WIRE PPL/LT GRN WIRE PPL/VIO WIRE RED WIRE TELLTALES THROTTLE BODY W/ THROTTLE POSITION SENSOR ASSEMBLY TRANSMISSION FLOOR SHIFT ASSEMBLY VIO WIRE WHT WIRE

Go to component: -> Cruise control circuit (2 of 2) -> THROTTLE BODY W/ THROTTLE POSITION SENSOR ASSEMBLY

Wiring diagram throttle body w/ throttle position sensor assembly (3 of 3)

Wiring diagram throttle body w/ throttle position sensor assembly for Lexus NX Z10 (2014-2017)

Get access

BLK WIRE BLU WIRE CAM TIMING OIL CONTROL MOTOR W/ EDU ASSEMBLY CAMSHAFT POSITION SENSOR (INTAKE SIDE) ECM (LEFT SIDE OF ENGINE COMPT) EPEO EPFL EPR GRN WIRE LIN LT GRN WIRE NE+ OIL PRESSURE CONTROL VALVE ASSEMBLY PNK WIRE RED WIRE STARTING/ CHARGING SYSTEM THROTTLE BODY W/ THROTTLE POSITION SENSOR ASSEMBLY VCPF VCPR VCVG VIO WIRE VTD VTM VTP VTS VVI+ WHT WIRE WHT/BLK WIRE WPI

Go to component: -> Wiring diagram engine performance 2.5l (3 of 10) -> THROTTLE BODY W/ THROTTLE POSITION SENSOR ASSEMBLY
