Lexus NX Z10 (2014-2017) stereo component equalizer assembly Wiring diagrams

This page contains all the electrical diagrams for the component. stereo component equalizer assembly, in which he is found in the car Lexus NX Z10 (2014-2017). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram stereo component equalizer assembly (1 of 5)

Go to component: -> Active sound control circuit -> STEREO COMPONENT EQUALIZER ASSEMBLY

Wiring diagram stereo component equalizer assembly (2 of 5)

Go to component: -> Computer data lines circuit (5 of 9) -> STEREO COMPONENT EQUALIZER ASSEMBLY

Wiring diagram stereo component equalizer assembly (3 of 5)

Go to component: -> Ground distribution circuit (5 of 8) -> STEREO COMPONENT EQUALIZER ASSEMBLY

Wiring diagram stereo component equalizer assembly (4 of 5)

2.5L 2.5L HYBRID 2.5L, 2.4L TURBO W/O TELEMATICS SYSTEM ABS 3 FUSE AIR CONDITIONING AMPLIFIER ASSEMBLY BLK WIRE BLU WIRE BRAKE BOOSTER CONTROL ECU (BRAKE BOOSTER W/ MASTER CYLINDER ASSEMBLY) COMPRESSOR W/ MOTOR ASSEMBLY D INJ FUSE D INJ RELAY DEICER RELAY ECU- IGP 1 FUSE ECU- IGP 2 FUSE ECU-IGP 3 FUSE EFI MAIN RELAY 2 EFI- MAIN 1 FUSE EFI- MAIN 1 RELAY EFI- MAIN 2 FUSE EFI- MAIN 3 FUSE EFI- MAIN RELAY 3 ENGINE ROOM R/B 2 ENGINE STOP, START ECU EPS FUSE FROM EFI 1 FUSE (DIAGRAM 3 OF 10) FUEL INJECTOR ASSEMBLY 1 (PORT INJECTION) FUEL INJECTOR ASSEMBLY 2 (PORT INJECTION) FUEL INJECTOR ASSEMBLY 3 (PORT INJECTION) FUEL INJECTOR ASSEMBLY 4 (PORT INJECTION) GRN WIRE GRY WIRE HYBRID VEHICLE CONTROL ECU IGCT RELAY IGNITION COIL ASSEMBLY 1 IGNITION COIL ASSEMBLY 2 IGNITION COIL ASSEMBLY 3 IGNITION COIL ASSEMBLY 4 IGP 1 RELAY IGP- MAIN 1 FUSE IGPT-IG FUSE INJ FUSE INV W/PMP 2 FUSE INV W/PMP RELAY LT BLU WIRE LT GRN WIRE NETWORK GATEWAY ECU OIL PMP FUSE OIL PMP RELAY ORG/ WIRE P/I FUSE PNK WIRE POWER STEERING ECU (RACK, PINION POWER STEERING GEAR ASSEMBLY) PPL PPL/BLK WIRE PPL/BLU WIRE PPL/GRN WIRE PPL/LT GRN WIRE PPL/PNK WIRE PTC HTR 1 RELAY PTC HTR 2 RELAY REAR SEAT HEATER SWITCH RED WIRE S/HTR 2 RELAY SEMICONDUCTOR POWER INTEGRATION ECU SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY) STEREO COMPONENT EQUALIZER ASSEMBLY STOP LIGHT SWITCH ASSEMBLY TO INSTRUMENT PANEL R/B 2 (DIAGRAM 2 OF 10) TO POWER DISTRIBUTION BOX ASSEMBLY (DIAGRAM 10 OF 10) TRANSMISSION FLOOR SHIFT ASSEMBLY VIO WIRE VVT FUSE VVT RELAY W/ TELEMATICS SYSTEM WASHER FUSE WHT WIRE WHT/BLK WIRE WINDSHIELD WIPER RELAY ASSEMBLY

Go to component: -> Power distribution circuit (4 of 10) -> STEREO COMPONENT EQUALIZER ASSEMBLY

Wiring diagram stereo component equalizer assembly (5 of 5)

Go to component: -> Power distribution circuit (6 of 10) -> STEREO COMPONENT EQUALIZER ASSEMBLY
