Lexus NX Z10 (2014-2017) shift up switch Wiring diagram
This page shows the only wiring diagram for the component.shift up switch, which is found in the car Lexus NX Z10 (2014-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram shift up switch (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
COOLING FANS SYSTEM
EFI 2 FUSE
EFI 5 FUSE
EFI 8 FUSE
EFI MAIN 2 RELAY
EFI- MAIN 1 FUSE
EFI- MAIN 1 RELAY
EFI- MAIN 2 FUSE
EFI- MAIN 3 FUSE
EFI- MAIN 3 RELAY
ENGINE ROOM R/B 1
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT GRN WIRE
ORG/ WIRE
PNK WIRE
PPL/BLK WIRE
PPL/BRN WIRE
PPL/GRN WIRE
PPL/LT GRN WIRE
PPL/VIO WIRE
RED WIRE
SDN
SHIFT UP SWITCH
SPIRAL CABLE SUB-ASSEMBLY
STEERING COLUMN)
SUP
TRANSMISSION SHIFT SWITCH
VIO WIRE
W/ POWER TILT, POWER TELESCOPE
W/O POWER TILT, POWER TELESCOPE
WHT WIRE
WHT/BLK WIRE
Go to component: -> Wiring diagram engine performance 2.4l turbo (2 of 9) -> SHIFT UP SWITCH
