Lexus NX Z10 (2014-2017) seat cushion) Wiring diagrams

This page contains all the electrical diagrams for the component. seat cushion), in which he is found in the car Lexus NX Z10 (2014-2017). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram seat cushion) (1 of 4)

Wiring diagram seat cushion) for Lexus NX Z10 (2014-2017)

Get access

BACK HEATER BFB- BLK WIRE BLU WIRE CERTIFICATION ECU COMPUTER DATA LINES SYSTEM CTB CUSHION BOLSTER HEATER CUSHION CENTER HEATER CXPI ECU-B 3 FUSE ENGINE ROOM R/B 1 GRN WIRE HOT AT ALL TIMES HTR IG PNK BFB+ WIRE IGPD INP STD FUSE LEFT FRONT SEAT CUSHION HEATER LEFT SEAT BACK CLIMATE CONTROL BLOWER LEFT SEAT CUSHION CLIMATE CONTROL BLOWER ASSEMBLY LEFT SEAT HEATER CONTROL SUB-ASSEMBLY LT GRN WIRE MAIN BODY ECU ORG/ WIRE PNK WIRE POWER DISTRIBUTION BOX ASSEMBLY PPL PPL/BLK WIRE PPL/BLU WIRE RED WIRE S/ HTR 1 RELAY S/HTR F/L FUSE S/HTR F/R FUSE SEAT BACK) SEAT CUSHION) SIGN PNK BBS WIRE SWR THR+ VIO WIRE W/ SEAT HEATER SWITCHING CIRCUIT TYPE 1 W/ SEAT HEATER SWITCHING CIRCUIT TYPE 2 WHT WIRE WHT/BLK WIRE

Go to component: -> Climate control seats circuit (1 of 2) -> SEAT CUSHION)

Wiring diagram seat cushion) (2 of 4)

Wiring diagram seat cushion) for Lexus NX Z10 (2014-2017)

Get access

AIR CONDITIONING AMPLIFIER ASSEMBLY BACK HEATER BFB- BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM CTB CUSHION BOLSTER HEATER CUSHION CENTER HEATER GRN WIRE GRY WIRE HTR IG PNK BFB+ WIRE LOUT LT BLU WIRE LT GRN WIRE PNK WIRE PPL RED WIRE RIGHT FRONT SEAT CUSHION HEATER RIGHT SEAT BACK CLIMATE CONTROL BLOWER RIGHT SEAT CUSHION CLIMATE CONTROL BLOWER ASSEMBLY RIGHT SEAT HEATER CONTROL SUB-ASSEMBLY ROUT SEAT BACK) SEAT CUSHION) SG-7 SHD SIGN PNK BBS WIRE SWR THR+ TSL TSR VIO WIRE WHT WIRE WHT/BLK WIRE

Go to component: -> Climate control seats circuit (2 of 2) -> SEAT CUSHION)

Wiring diagram seat cushion) (3 of 4)

Wiring diagram seat cushion) for Lexus NX Z10 (2014-2017)

Get access

BACK HEATER BLK WIRE BLU WIRE CERTIFICATION ECU COMPUTER DATA LINES SYSTEM CUSHION BOLSTER HEATER CUSHION CENTER HEATER CXPI ECU-B 3 FUSE ENGINE ROOM R/B 1 GRN WIRE HOT AT ALL TIMES HTR IGPD INP STD FUSE LEFT FRONT SEAT CUSHION HEATER LEFT SEAT HEATER CONTROL SUB-ASSEMBLY MAIN BODY ECU ORG/ WIRE PNK WIRE POWER DISTRIBUTION BOX ASSEMBLY PPL PPL/BLK WIRE PPL/BLU WIRE RED WIRE S/ HTR 1 RELAY S/HTR F/L FUSE S/HTR F/R FUSE SEAT BACK) SEAT CUSHION) SWR THR+ VIO WIRE W/ SEAT HEATER SWITCHING CIRCUIT TYPE 1 W/ SEAT HEATER SWITCHING CIRCUIT TYPE 2 WHT WIRE WHT/BLK WIRE

Go to component: -> Front heated seats circuit (1 of 2) -> SEAT CUSHION)

Wiring diagram seat cushion) (4 of 4)

Wiring diagram seat cushion) for Lexus NX Z10 (2014-2017)

Get access

AIR CONDITIONING AMPLIFIER ASSEMBLY BACK HEATER BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM CUSHION BOLSTER HEATER CUSHION CENTER HEATER GRN WIRE HTR LT BLU WIRE PNK WIRE PPL RED WIRE RIGHT FRONT SEAT CUSHION HEATER RIGHT SEAT HEATER CONTROL SUB-ASSEMBLY SEAT BACK) SEAT CUSHION) SG-7 SHD SWR THR+ TSL TSR VIO WIRE WHT WIRE WHT/BLK WIRE

Go to component: -> Front heated seats circuit (2 of 2) -> SEAT CUSHION)
