Lexus NX Z10 (2014-2017) power switch Wiring diagram
This page shows the only wiring diagram for the component.power switch, which is found in the car Lexus NX Z10 (2014-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power switch (1 of 1)
AGND
BLK WIRE
BLU WIRE
CERTIFICATION ECU
CLEARANCE WARNING ECU ASSEMBLY
COMBINATION SWITCH ASSEMBLY
ECU-IGR 3 FUSE
ELECTRICAL KEY, TIRE PRESSURE MONITORING SYSTEM RECEIVER ASSEMBLY
FROM +BA RELAY (DIAGRAM 8 OF 10)
FROM ENGINE ROOM R/B 1 (DIAGRAM 4 OF 10)
FROM ENGINE STOP, START ECU (DIAGRAM 3 OF 10)
FROM IGR 2 RELAY (DIAGRAM 7 OF 10)
FROM P/OUTLET RELAY (DIAGRAM 7 OF 10)
FROM POWER DISTRIBUTION BOX ASSEMBLY (DIAGRAM 7 OF 10)
GLOVE BOX LIGHT ASSEMBLY
GRN WIRE
GRY WIRE
HAZARD WARNING SIGNAL SWITCH ASSEMBLY
IGR 1 RELAY
INTEGRATION CONTROL, PANEL ASSEMBLY
METER MIRROR SUB-ASSEMBLY
ORG/ WIRE
PNK WIRE
POWER SWITCH
PPL
PPL/BLK WIRE
PPL/BLU WIRE
PPL/BRN WIRE
PPL/GRN WIRE
PPL/VIO WIRE
PPL/WHT WIRE
RED WIRE
RIGHT FRONT DOOR CONTROL SWITCH ASSEMBLY
TO A/BAG-IGR FUSE (DIAGRAM 9 OF 10)
TO MOBILE WIRELESS CHARGER CRADLE ASSEMBLY (DIAGRAM 2 OF 10)
W/ STOP/ START SYSTEM
W/O STOP/ START SYSTEM
WHT) PPL/VIO WIRE
Go to component: -> Power distribution circuit (10 of 10) -> POWER SWITCH
