Lexus NX Z10 (2014-2017) p con mtr fuse Wiring diagrams

This page contains all the electrical diagrams for the component. p con mtr fuse, in which he is found in the car Lexus NX Z10 (2014-2017). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram p con mtr fuse (1 of 3)

Wiring diagram p con mtr fuse for Lexus NX Z10 (2014-2017)

Get access

BBC 2 FUSE BIN 2 BLK WIRE BLU WIRE BRN WIRE CAN I/F COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM DISPLAY DRIVER ECU-IGR 13 FUSE ENGINE ROOM R/B 1 ENGINE STOP, START ECU GRY WIRE HOT AT ALL TIMES HOT W/ IGR 1 RELAY ENERGIZED HOT W/ IGR 2 RELAY ENERGIZED LT GRN WIRE METER-IGR FUSE P CON MTR FUSE PNK WIRE POWER DISTRIBUTION BOX ASSEMBLY PPL PPL/VIO WIRE RED WIRE SHIFT CONTROL ACTUATOR ASSEMBLY W/ STOP/ START SYSTEM W/O STOP/ START SYSTEM WAKE WHT WIRE WHT/BLK WIRE

Go to component: -> A/t circuit (4 of 4) -> P CON MTR FUSE

Wiring diagram p con mtr fuse (2 of 3)

Wiring diagram p con mtr fuse for Lexus NX Z10 (2014-2017)

Get access

2.5L 2.5L HYBRID 2.5L, 2.4L TURBO ABS 3 FUSE ABS- MAIN FUSE BATT-S 1 FUSE BATT-S 2 FUSE BATTERY BATTERY STATE SENSOR ASSEMBLY BKUP LP RELAY BLK WIRE BLOWER MOTOR W/ FAN SUB-ASSEMBLY BLU WIRE BRAKE BOOSTER CONTROL ECU (BRAKE BOOSTER W/ MASTER CYLINDER ASSEMBLY) DC/DC ALT FUSE E-LATCH 1 FUSE E-LATCH 3 FUSE ENGINE ROOM J/B 1 FAN FUSE FAN W/ MOTOR ASSEMBLY FOG RR RELAY FROM LUGGAGE ROOM R/B 1 (DIAGRAM 1 OF 10) FUSIBLE LINK BLOCK GENERATOR ASSEMBLY GRN WIRE HTR FUSE INP STD 1 FUSE INP STD 2 FUSE INVERTER W/ CONVERTER ASSEMBLY LT BLU WIRE MAIN 2 FUSE MAIN FUSE MG FUSE NCA WIRE NOISE FILTER FUSE P CON MAIN FUSE P CON MTR FUSE PNK WIRE POWER DISTRIBUTION BOX ASSEMBLY (LEFT END OF DASH) PPL PPL/GRN WIRE PPL/RED WIRE R/B 2 FUSE R/B 4 FUSE RADIO SETTING CONDENSER RED WIRE RIGHT FRONT DOOR LOCK W/ MOTOR ASSEMBLY RIGHT REAR DOOR LOCK W/ MOTOR ASSEMBLY RR DEF RELAY SHIFT CONTROL ACTUATOR ASSEMBLY SPIRAL CABLE SUB-ASSEMBLY STARTER ASSEMBLY STEERING COLUMN) STRG HTR FUSE TO D/C CUT FUSE (DIAGRAM 3 OF 10) TO ENGINE ROOM J/B 2 (DIAGRAM 2 OF 10) TO LUGGAGE ROOM R/B 1 (DIAGRAM 1 OF 10) TO POWER DISTRIBUTION ASSEMBLY (DIAGRAM 5 OF 10) TOWING-B FUSE TRANSMISSION FLOOR SHIFT ASSEMBLY VIO WIRE WHT WIRE WHT/BLK WIRE

Go to component: -> Power distribution circuit (1 of 10) -> P CON MTR FUSE

Wiring diagram p con mtr fuse (3 of 3)

Wiring diagram p con mtr fuse for Lexus NX Z10 (2014-2017)

Get access

2.5L AA (LEFT SIDE OF ENGINE COMPT) BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM ECU-IGP 3 FUSE ECU-IGR 2 FUSE ENGINE ROOM R/B 1 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGP 1 RELAY ENERGIZED HOT W/ IGR 2 RELAY ENERGIZED P CON MAIN FUSE P CON MTR FUSE PNK WIRE POWER DISTRIBUTION BOX ASSEMBLY PPL PPL/PNK WIRE PPL/RED WIRE PPL/WHT WIRE RED WIRE SHIFT CONTROL ACTUATOR ASSEMBLY STOP FUSE STOP LIGHT SWITCH ASSEMBLY WAKE WHT WIRE WHT/BLK WIRE

Go to component: -> Shift interlock circuit (1 of 2) -> P CON MTR FUSE
