Lexus NX Z10 (2014-2017) oil pressure/ temperature sensor Wiring diagram

This page shows the only wiring diagram for the component.oil pressure/ temperature sensor, which is found in the car Lexus NX Z10 (2014-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram oil pressure/ temperature sensor (1 of 1)

Wiring diagram oil pressure/ temperature sensor for Lexus NX Z10 (2014-2017)

Get access

BLK WIRE BLU WIRE BRN WIRE EFI 4 FUSE EFI 8 FUSE EFI MAIN RELAY 1 EFI MAIN RELAY 2 EFI- MAIN 1 FUSE EFI- MAIN 2 FUSE EFI- MAIN 3 FUSE EFI- MAIN RELAY 3 ENGINE ROOM R/B 1 FUEL PRESSURE SENSOR (HIGH PRESSURE SIDE) FUEL PRESSURE SENSOR (LOW PRESSURE SIDE) GRN WIRE HOT AT ALL TIMES INTAKE MASS AIR FLOW METER SUB-ASSEMBLY KNOCK CONTROL SENSOR LT GRN WIRE OIL PRESSURE/ TEMPERATURE SENSOR ORG/ WIRE PFL PNK WIRE RED WIRE SHIELD THA TOUT VCC VIO WIRE VVT FUSE VVT RELAY WHT WIRE WHT/BLK WIRE

Go to component: -> Wiring diagram engine performance 2.5l (4 of 10) -> OIL PRESSURE/ TEMPERATURE SENSOR
