Lexus NX Z10 (2014-2017) lumbar support switch Wiring diagram
This page shows the only wiring diagram for the component.lumbar support switch, which is found in the car Lexus NX Z10 (2014-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lumbar support switch (1 of 1)
BLK WIRE
BLU WIRE
DOWN
FDWN
FRONT
FRONT VERTICAL SWITCH
FUP
GRN WIRE
GRY WIRE
HOLD
HOT AT ALL TIMES
LDWN
LEFT FRONT POWER SEAT LUMBAR SUPPORT MOTOR
LEFT FRONT POWER SEAT SLIDE MOTOR (LEFT FRONT SEAT ADJUSTER ASSEMBLY)
LEFT FRONT POWER SEAT SWITCH
LEFT POWER SEAT LIFTER MOTOR ASSEMBLY
LEFT POWER SEAT RECLINING MOTOR
LEFT POWER SEAT TILT MOTOR ASSEMBLY
LIFTER SWITCH
LT BLU WIRE
LT GRN WIRE
LUMBAR SUPPORT SWITCH
LUP
P/SEAT F/L FUSE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
RCLF
RCLR
REAR
RECLINING SWITCH
RED WIRE
RELEASE
SLDF
SLDR
SLIDE SWITCH
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component: -> Driver power seat circuit -> LUMBAR SUPPORT SWITCH
