Lexus NX Z10 (2014-2017) luggage compartment light assembly 1 Wiring diagram

BACK DOOR LOCK W/ COURTESY LIGHT SWITCH ASSEMBLY BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM CTY CXPI DOME CUT RELAY DOME CUT RELAY 2 (EXCEPT HYBRID) DOME FUSE ECU-IGR 2 FUSE ENGINE ROOM R/B 1 EXCEPT HYBRID FOLD SEAT SWITCH ASSEMBLY FSPT GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGR 2 RELAY ENERGIZED IGR ILL INSTRUMENT PANEL R/B 2 (RIGHT END OF DASH) LEFT LUGGAGE COMPARTMENT LIGHT ASSEMBLY 1 LOWER LT GRN WIRE LUGGAGE COMPARTMENT LIGHT ASSEMBLY 1 MAIN BODY ECU (LEFT END OF DASH) OLP P/I FUSE POWER DISTRIBUTION BOX ASSEMBLY PPL PPL/BLK WIRE PPL/BLU WIRE PPL/LT GRN WIRE PPL/PNK WIRE RED WIRE RIGHT END OF DASH) RIGHT LUGGAGE COMPARTMENT LIGHT ASSEMBLY 1 RIGHT LUGGAGE COMPARTMENT LIGHT ASSEMBLY 2 SEMICONDUCTOR POWER INTEGRATION ECU VIO WIRE WHT WIRE WHT/BLK WIRE
