Lexus NX Z10 (2014-2017) left rear active noise control microphone Wiring diagram
This page shows the only wiring diagram for the component.left rear active noise control microphone, which is found in the car Lexus NX Z10 (2014-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear active noise control microphone (1 of 1)
ACNT
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
ECM (2.4L TURBO) (LEFT SIDE OF ENGINE COMPT)
ECU-B 2 FUSE
ECU-IGP 3 FUSE
GRN WIRE
HOT AT ALL TIMES
IGP
J/C 22 (146)
LEFT FRONT ACTIVE NOISE CONTROL MICROPHONE
LEFT REAR ACTIVE NOISE CONTROL MICROPHONE
LT BLU WIRE
LT GRN WIRE
NEI
NEO
ORG/ WIRE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
PPL
PPL/BLK WIRE
PPL/BLU WIRE
PPL/BRN WIRE
PPL/GRN WIRE
PPL/LT BLU WIRE
PPL/LT GRN WIRE
PPL/RED WIRE
PPL/VIO WIRE
PPL/YEL WIRE
RED WIRE
RELAY ENERGIZED
RIGHT FRONT ACTIVE NOISE CONTROL MICROPHONE
RIGHT REAR ACTIVE NOISE CONTROL MICROPHONE
SHIELD
STEREO COMPONENT AMPLIFIER ASSEMBLY
STEREO COMPONENT EQUALIZER ASSEMBLY
VIO WIRE
WHT WIRE
Go to component: -> Active sound control circuit -> LEFT REAR ACTIVE NOISE CONTROL MICROPHONE
