Lexus NX Z10 (2014-2017) left power seat reclining motor Wiring diagrams

BLK WIRE BLU WIRE DOWN FDWN FRONT FRONT VERTICAL SWITCH FUP GRN WIRE GRY WIRE HOLD HOT AT ALL TIMES LDWN LEFT FRONT POWER SEAT LUMBAR SUPPORT MOTOR LEFT FRONT POWER SEAT SLIDE MOTOR (LEFT FRONT SEAT ADJUSTER ASSEMBLY) LEFT FRONT POWER SEAT SWITCH LEFT POWER SEAT LIFTER MOTOR ASSEMBLY LEFT POWER SEAT RECLINING MOTOR LEFT POWER SEAT TILT MOTOR ASSEMBLY LIFTER SWITCH LT BLU WIRE LT GRN WIRE LUMBAR SUPPORT SWITCH LUP P/SEAT F/L FUSE PNK WIRE POWER DISTRIBUTION BOX ASSEMBLY RCLF RCLR REAR RECLINING SWITCH RED WIRE RELEASE SLDF SLDR SLIDE SWITCH VIO WIRE WHT WIRE WHT/BLK WIRE

BLK WIRE BLU WIRE BRN WIRE CANN CANN PNK CANP WIRE CANP COMPUTER DATA LINES SYSTEM CPUB DBCL DOWN ECU- DCC 3 FUSE ECU-IGR 1 FUSE FDWN FRONT FRONT VERTICAL FRV- FRVD FUP UP GRN WIRE GRY WIRE HOLD HOT AT ALL TIMES HOT W/ IGR 1 RELAY ENERGIZED LDWN LEFT FRONT POSITION CONTROL ECU ASSEMBLY LEFT FRONT POWER SEAT LUMBAR SUPPORT MOTOR LEFT FRONT POWER SEAT SLIDE MOTOR LEFT FRONT POWER SEAT SWITCH LEFT FRONT SEAT INNER BELT ASSEMBLY LEFT OUTER MIRROR CONTROL ECU ASSEMBLY LEFT POWER SEAT LIFTER MOTOR ASSEMBLY LEFT POWER SEAT RECLINING MOTOR LEFT POWER SEAT TILT MOTOR ASSEMBLY LEFT SEAT MEMORY SWITCH LFLF LFLR LFT- LFTD LFTU LIFTER LT BLU WIRE LT GRN WIRE LUMBAR LUP LV (+) LVD LVU MMRY P/SEAT F/L FUSE PNK WIRE POWER DISTRIBUTION BOX ASSEMBLY PPL PPL GND PPL PPL PPL/BLK WIRE PPL/GRN WIRE PPL/LT GRN WIRE PPL/RED WIRE PPL/VIO WIRE RCL- RCLF RCLR RCLR REAR REAR SLDR RECLINING RED WIRE RELEASE SENG SLD SLDF SLDR SLIDE SSFV SSRR SSRS SYSB VIO WIRE WHT WIRE WHT/BLK WIRE
