Lexus NX Z10 (2014-2017) left front speaker assembly 3 Wiring diagrams

This page contains all the electrical diagrams for the component. left front speaker assembly 3, in which he is found in the car Lexus NX Z10 (2014-2017). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram left front speaker assembly 3 (1 of 2)

Wiring diagram left front speaker assembly 3 for Lexus NX Z10 (2014-2017)

Get access

ACNT AMP 1 FUSE BLK WIRE BLU WIRE CTR + DB (UPPER RIGHT CENTER OF DASH) FRONT SPEAKER ASSEMBLY 4 GRN WIRE HOT AT ALL TIMES LEFT FRONT SPEAKER ASSEMBLY 1 LEFT FRONT SPEAKER ASSEMBLY 3 LEFT REAR SPEAKER ASSEMBLY 2 LT BLU WIRE LT GRN WIRE ORG/ WIRE PNK WIRE POWER DISTRIBUTION BOX ASSEMBLY PPL/BLK WIRE PPL/BLU WIRE PPL/GRN WIRE PPL/LT BLU WIRE PPL/LT GRN WIRE PPL/RED WIRE PPL/WHT WIRE RED WIRE RIGHT FRONT SPEAKER ASSEMBLY 1 RIGHT FRONT SPEAKER ASSEMBLY 2 RIGHT REAR SPEAKER ASSEMBLY 2 SHIELD SOUND SYSTEMS SPEAKER W/ BOX ASSEMBLY 1 STEREO COMPONENT AMPLIFIER ASSEMBLY TMUT TWL- TWR+ VIO WIRE W/O NAVIGATION WFL- WFR- WHT WIRE

Go to component: -> Navigation circuit (5 of 5) -> LEFT FRONT SPEAKER ASSEMBLY 3
