Lexus NX Z10 (2014-2017) inv fuse Wiring diagram
This page shows the only wiring diagram for the component.inv fuse, which is found in the car Lexus NX Z10 (2014-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram inv fuse (1 of 1)
4 WHEEL DRIVE CONTROL ECU
AVS FUSE
AWD FUSE
BLK WIRE
BLU WIRE
CERTIFICATION ECU
COMPUTER DATA LINES SYSTEM
DC (RIGHT SIDE OF DASH)
DEICER FUSE
DEICER RELAY
ENGINE ROOM J/B 2
EXCD
FOLD SEAT CONTROL ECU
FROM ENGINE ROOM R/B 1 (DIAGRAM 1 OF 10)
GRN WIRE
GRY WIRE
H-LP CLN FUSE
H-LP CLN RELAY
HWD 1 FUSE
HWD 2 FUSE
IGR 3 RELAY INSTRUMENT PANEL R/B 2
INSTRUMENT PANEL R/B 2
INV FUSE
INV RELAY
LT GRN WIRE
MOBILE WIRELESS CHARGER CRADLE ASSEMBLY
P/SEAT (FR) FUSE
P/SEAT (RR) FUSE
P/SEAT R/L FUSE
PNK WIRE
POWER OUTLET SOCKET
PPL
PPL/BLK WIRE
PPL/GRN WIRE
PPL/RED WIRE
PPL/VIO WIRE
PTC HTR 1 FUSE
PTC HTR 1 RELAY
PTC HTR 2 FUSE
PTC HTR 2 RELAY
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT POWER SEAT SWITCH
S/HTR 2 RELAY
S/HTR- MAIN FUSE
SDET
TAIL
TOWING- ALT FUSE
VIO WIRE
VOLTAGE INVERTER ASSEMBLY (IF EQUIPPED) (LEFT SIDE OF LUGGAGE COMPT)
VV-
WCSW
WHT WIRE
WHT/BLK WIRE
Go to component: -> Power distribution circuit (2 of 10) -> INV FUSE
