Lexus NX AZ20 (2021-2024) Integration control and panel circuit

Integration control and panel circuit

Car Wiring Diagrams for NX Lexus AZ20 (2021-2024): Integration control and panel circuit

BLK WIRE BLSW BLU WIRE BRN WIRE ECU-IGR 1 FUSE ENGINE CONTROLS SYSTEM HOT W/ IGR 1 RELAY ENERGIZED INTEGRATION CONTROL, PANEL ASSEMBLY MAIN BODY ECU NAVIGATION SYSTEM PBDS POWER DISTRIBUTION BOX ASSEMBLY PPL PPL DB PPL/BLK WIRE PPL/BLU WIRE PPL/LT GRN WIRE PPL/RED WIRE PPL/VIO WIRE VIO WIRE
