Lexus NX AZ20 (2021-2024) w/o parking support brake Wiring diagram
This page shows the only wiring diagram for the component.w/o parking support brake, which is found in the car Lexus NX AZ20 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o parking support brake (1 of 1)
BLK WIRE
BLU WIRE
CAN JUNCTION TERMINAL 4
FSGD
GB (RIGHT SIDE OF LUGGAGE COMPT)
GRN WIRE
GRY WIRE
LEFT BLIND SPOT MONITOR SENSOR
LEFT FRONT SIDE RADAR SENSOR
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
PPL
RED WIRE
RIGHT BLIND SPOT MONITOR SENSOR
RIGHT FRONT SIDE RADAR SENSOR
VIO WIRE
W/O PARKING SUPPORT BRAKE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Computer data lines circuit (4 of 9) -> W/O PARKING SUPPORT BRAKE
