Lexus NX AZ20 (2021-2024) tilt motor Wiring diagrams
This page contains all the electrical diagrams for the component. tilt motor, in which he is found in the car Lexus NX AZ20 (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram tilt motor (1 of 2)
BLU WIRE
CANN
CANP
COMPUTER DATA LINES SYSTEM
CPUB
DD (LEFT SIDE OF DASH)
DRIVER'S DOOR
ECU- DCC 3 FUSE
ECU-IGR 1 FUSE
ECUB
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGR 1 RELAY ENERGIZED
LEFT OUTER MIRROR CONTROL ECU ASSEMBLY
LEFT SEAT MEMORY SWITCH
LT BLU WIRE
LT GRN WIRE
MMRY
MSW
MULTIPLEX TILT, TELESCOPIC ECU
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
PPL
PPL DD (LEFT SIDE OF DASH)
PPL/BLK WIRE
PPL/BLU WIRE
PPL/GRN WIRE
PPL/LT BLU WIRE
PPL/RED WIRE
PPL/VIO WIRE
RED WIRE
STEERING COLUMN ASSEMBLY
STEERING COLUMN)
TELESCOPIC MOTOR
TELESCOPIC SHORTEN
TELESCOPIC STRETCH
TEM
TES
TI, TE FUSE
TILT DOWN
TILT MOTOR
TILT UP
TILT, TELESCOPIC SWITCH
TIM
TIS
VCE
VCI
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Memory power tilt & power telescopic circuit -> TILT MOTOR
Wiring diagram tilt motor (2 of 2)
BLU WIRE
CANN
CANP
COMPUTER DATA LINES SYSTEM
DB (UPPER RIGHT CENTER OF DASH)
ECU- DCC 3 FUSE
ECU-IGR 1 FUSE
ECUB
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGR 1 RELAY ENERGIZED
LT BLU WIRE
LT GRN WIRE
MSW
MULTIPLEX TILT, TELESCOPIC ECU
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
PPL
PPL/BLK WIRE
PPL/BLU WIRE
PPL/GRN WIRE
PPL/RED WIRE
STEERING COLUMN ASSEMBLY
STEERING COLUMN)
TELESCOPIC MOTOR
TELESCOPIC SHORTEN
TELESCOPIC STRETCH
TEM
TES
TI, TE FUSE
TILT DOWN
TILT MOTOR
TILT UP
TILT, TELESCOPIC SWITCH
TIM
TIS
VCE
VCI
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power tilt steering column circuit -> TILT MOTOR
