Lexus NX AZ20 (2021-2024) spot light assembly Wiring diagram
This page shows the only wiring diagram for the component.spot light assembly, which is found in the car Lexus NX AZ20 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram spot light assembly (1 of 1)
AMD 2 FUSE
BLK WIRE
BLU WIRE
CBMN
CBMP
CBSW
COMPUTER DATA LINES SYSTEM
CPLT
ECU-B 4 FUSE
ELECTRIC VEHICLE CHARGER ASSEMBLY (REAR OF HV BATTERY ASSEMBLY)
ENGINE ROOM R/B 2
FANG
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IGCT
LDLP
LDSW
LT BLU WIRE
LUGGAGE ROOM R/B 1
ORG/BLK WIRE
ORG/BLU WIRE
ORG/LT GRN WIRE
ORG/WHT WIRE
PIL-
PISW
PNK WIRE
PPL
PPL/BLK WIRE
PPL/BLU WIRE
PPL/GRN WIRE
PPL/LT BLU WIRE
PPL/PNK WIRE
PPL/RED WIRE
PPL/WHT WIRE
RED WIRE
SHIELD
SPOT LIGHT ASSEMBLY
THERMISTOR
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Wiring diagram engine performance 2.5l hybrid, hybrid system circuit (9 of 13) -> SPOT LIGHT ASSEMBLY
