Lexus NX AZ20 (2021-2024) seat cushion) Wiring diagrams
This page contains all the electrical diagrams for the component. seat cushion), in which he is found in the car Lexus NX AZ20 (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram seat cushion) (1 of 4)
BACK HEATER
BFB-
BLK WIRE
BLU WIRE
CTB
CUSHION BOLSTER HEATER
CUSHION CENTER HEATER
ENGINE ROOM R/B 1
GRN WIRE
HOT AT ALL TIMES
HTR
INP STD 2 FUSE
LEFT FRONT SEAT CUSHION HEATER (LEFT FRONT SEAT CUSHION PAD)
LEFT SEAT BACK CLIMATE CONTROL BLOWER (LEFT FRONT SEAT)
LEFT SEAT CUSHION CLIMATE CONTROL BLOWER ASSEMBLY (LEFT FRONT SEAT)
LEFT SEAT HEATER CONTROL SUB-ASSEMBLY (LEFT FRONT SEAT)
LT GRN WIRE
PNK BFB+ WIRE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
PPL
PPL/BLK WIRE
PPL/BLU WIRE
RED WIRE
S/ HTR 1 RELAY
S/HTR F/L FUSE
S/HTR F/R FUSE
SEAT BACK)
SEAT CUSHION)
SIGN PNK BBS WIRE
SWR
THR+
VIO WIRE
WHT/BLK WIRE
Go to component -> Climate control seats circuit (1 of 2) -> SEAT CUSHION)
Wiring diagram seat cushion) (2 of 4)
A/C AMPLIFIER ASSEMBLY
BACK HEATER
BFB-
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
CTB
CUSHION BOLSTER HEATER
CUSHION CENTER HEATER
ECU-B 3 FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HTR
LOUT
LT BLU WIRE
LT GRN WIRE
PNK BFB+ WIRE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
PPL
PPL/BLU WIRE
RED WIRE
RIGHT FRONT SEAT CUSHION HEATER (RIGHT FRONT SEAT CUSHION PAD)
RIGHT SEAT BACK CLIMATE CONTROL BLOWER (RIGHT FRONT SEAT)
RIGHT SEAT CUSHION CLIMATE CONTROL BLOWER ASSEMBLY (RIGHT FRONT SEAT)
RIGHT SEAT HEATER CONTROL SUB-ASSEMBLY (RIGHT FRONT SEAT)
ROUT
SEAT BACK)
SEAT CUSHION)
SG-7
SIGN PNK BBS WIRE
SMIL
SWR
THR+
TSL
TSR
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Climate control seats circuit (2 of 2) -> SEAT CUSHION)
Wiring diagram seat cushion) (3 of 4)
BACK HEATER
BLK WIRE
BLU WIRE
CUSHION BOLSTER HEATER
CUSHION CENTER HEATER
ENGINE ROOM R/B 1
GRN WIRE
HOT AT ALL TIMES
HTR
INP STD 2 FUSE
LEFT FRONT SEAT CUSHION HEATER (LEFT FRONT SEAT CUSHION PAD)
LEFT SEAT HEATER CONTROL SUB-ASSEMBLY (LEFT FRONT SEAT)
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
PPL
PPL/BLK WIRE
PPL/BLU WIRE
RED WIRE
S/ HTR 1 RELAY
S/HTR F/L FUSE
S/HTR F/R FUSE
SEAT BACK)
SEAT CUSHION)
SWR
THR+
VIO WIRE
WHT/BLK WIRE
Go to component -> Front heated seats circuit (1 of 2) -> SEAT CUSHION)
Wiring diagram seat cushion) (4 of 4)
A/C AMPLIFIER ASSEMBLY
BACK HEATER
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
CUSHION BOLSTER HEATER
CUSHION CENTER HEATER
ECU-B 3 FUSE
GRN WIRE
HOT AT ALL TIMES
HTR
LT BLU WIRE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
PPL
PPL/BLU WIRE
RED WIRE
RIGHT FRONT SEAT CUSHION HEATER (RIGHT FRONT SEAT CUSHION PAD)
RIGHT SEAT HEATER CONTROL SUB-ASSEMBLY (RIGHT FRONT SEAT)
SEAT BACK)
SEAT CUSHION)
SG-7
SMIL
SWR
THR+
TSL
TSR
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Front heated seats circuit (2 of 2) -> SEAT CUSHION)
