Lexus NX AZ20 (2021-2024) right rear door inside handle sub-assembly Wiring diagrams

This page contains all the electrical diagrams for the component. right rear door inside handle sub-assembly, in which he is found in the car Lexus NX AZ20 (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram right rear door inside handle sub-assembly (1 of 4)

Wiring diagram right rear door inside handle sub-assembly for Lexus NX AZ20 (2021-2024) (1 of 4)

Get access

ACAN AUTOMATIC LIGHT CONTROL SENSOR BLK WIRE BLU WIRE CLTB CLTE CLTS DMDR DMON DOOR LOCKS SYSTEM GRN WIRE GRY WIRE HEAD LT BLU WIRE LT GRN WIRE ORG/ WIRE PNK WIRE PPL PPL/BLK WIRE PPL/BLU WIRE PPL/GRN WIRE PPL/GRY WIRE PPL/LT BLU WIRE PPL/PNK WIRE PPL/RED WIRE PPL/VIO WIRE PPL/WHT WIRE RED WIRE RIGHT FRONT INTERIOR ILLUMINATION LIGHT ASSEMBLY 2 RIGHT REAR DOOR RIGHT REAR DOOR INSIDE HANDLE SUB-ASSEMBLY RIGHT REAR INTERIOR ILLUMINATION LIGHT ASSEMBLY 2 ULIN W/O DOOR TRIM ILLUMINATION W/O ILLUMINATION ECU WHT WIRE

Go to component -> Courtesy lamps circuit (4 of 7) -> RIGHT REAR DOOR INSIDE HANDLE SUB-ASSEMBLY

Wiring diagram right rear door inside handle sub-assembly (2 of 4)

Wiring diagram right rear door inside handle sub-assembly for Lexus NX AZ20 (2021-2024) (2 of 4)

Get access

BLK WIRE BLU WIRE DA (RIGHT SIDE OF DASH) EREP ERER GRN WIRE GRY WIRE ILL INTEGRATION CONTROL SUPPLY LT BLU WIRE LT GRN WIRE OLP ORG/ WIRE PCTY PNK WIRE POWER DISTRIBUTION SYSTEM PPL PPL/BLK WIRE PPL/BLU WIRE PPL/GRN WIRE PPL/LT BLU WIRE PPL/LT GRN WIRE PPL/PNK WIRE PPL/RED WIRE RED WIRE RIGHT FRONT DOOR CONTROL SWITCH ASSEMBLY RIGHT FRONT DOOR INSIDE HANDLE SUB-ASSEMBLY RIGHT FRONT DOOR LOCK W/ MOTOR ASSEMBLY RIGHT FRONT DOOR OUTSIDE HANDLE ASSEMBLY RIGHT REAR DOOR RIGHT REAR DOOR CONTROL SWITCH ASSEMBLY RIGHT REAR DOOR INSIDE HANDLE SUB-ASSEMBLY RIGHT REAR DOOR LOCK W/ MOTOR ASSEMBLY RIGHT REAR DOOR OUTSIDE HANDLE ASSEMBLY TRG+ ULIN VIO WIRE WHT WIRE WHT/BLK WIRE

Go to component -> Forced entry circuit (6 of 8) -> RIGHT REAR DOOR INSIDE HANDLE SUB-ASSEMBLY
