Lexus NX AZ20 (2021-2024) right front position control ecu assembly Wiring diagrams
This page contains all the electrical diagrams for the component. right front position control ecu assembly, in which he is found in the car Lexus NX AZ20 (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right front position control ecu assembly (1 of 2)
Go to component -> Body ecu circuit (2 of 3) -> RIGHT FRONT POSITION CONTROL ECU ASSEMBLY
Wiring diagram right front position control ecu assembly (2 of 2)
BLK WIRE
BLU WIRE
DBCL
DRDC
ECU-IGR 1 FUSE
HOT W/ IGR 1 RELAY ENERGIZED
LEFT FRONT SEAT INNER BELT ASSEMBLY
LEFT TENSION REDUCER (LEFT FRONT SEAT OUTER BELT ASSEMBLY)
LT GRN WIRE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
PPL
PPL/VIO WIRE
RED WIRE
RIGHT FRONT POSITION CONTROL ECU ASSEMBLY
RIGHT FRONT SEAT INNER BELT ASSEMBLY
RIGHT TENSION REDUCER (RIGHT FRONT SEAT OUTER BELT ASSEMBLY)
VIO WIRE
W/ MEMORY
W/O MEMORY
WHT/BLK WIRE
Go to component -> Passive restraints circuit -> RIGHT FRONT POSITION CONTROL ECU ASSEMBLY
