Lexus NX AZ20 (2021-2024) right front corner ultrasonic sensor Wiring diagram
This page shows the only wiring diagram for the component.right front corner ultrasonic sensor, which is found in the car Lexus NX AZ20 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front corner ultrasonic sensor (1 of 1)
BLK WIRE
BLU WIRE
LEFT FRONT CENTER ULTRASONIC SENSOR
LEFT FRONT CORNER ULTRASONIC SENSOR
LEFT FRONT SIDE ULTRASONIC SENSOR
LEFT REAR SIDE ULTRASONIC SENSOR
PPL/BLK WIRE
PPL/BLU WIRE
PPL/GRN WIRE
PPL/LT GRN WIRE
PPL/RED WIRE
PPL/VIO WIRE
RIGHT FRONT CENTER ULTRASONIC SENSOR
RIGHT FRONT CORNER ULTRASONIC SENSOR
RIGHT FRONT SIDE ULTRASONIC SENSOR
RIGHT REAR SIDE ULTRASONIC SENSOR
VIO WIRE
Go to component -> Rear sonar circuit (2 of 2) -> RIGHT FRONT CORNER ULTRASONIC SENSOR
